Connector signals
RS-232C REMOTE (25-pin D-SUB straight cable supported)
Pin No. Abbreviation
Circuit
Description
1 FRAME GROUND Protective ground Frame ground
2
T×D Transmitted data
Receives data from the PC.
3
R×D
Received data
Sends data to the PC.
4
RTS
Request to send
Shorted with pin 4.
5
CTS Clear to send
Shorted with pin 5.
6
DSR
Data set ready
Positive power output after communication enable
status
7 GND Signal ground
Signal ground
20
DTR Data terminal ready No processing
• Example of connections with controller (PC) using a 25-pin D-SUB straight cable
PC end (D-SUB 25 pins)
VTR end (D-SUB 25 pins)
FG
1
T×D 2
R×D 3
RTS
4
CTS 5
DSR 6
GND 7
DTR 20
1
2
3
4
5
6
7
20
FG
T×D
RxD
RTS
CTS
DSR
GND
DTR
ENCODER REMOTE (15P)
Pin No. Signal
Pin No. Signal Pin No.
Signal
1
6
SYSTEM H
11 RET GND
2 SET UP
7 SYS.SC COARSE (2)
12
3 C LEVEL
8 –12V
13
4 GND
9 HUE
14
SYS.SC FINE
5 +12V
10 VIDEO LEVEL
15 SYS.SC COARSE (1)
