Panasonic AJ-D650 - Performance Specifications

Specifications
GENERAL
Power supply:
Power consumption:
AC 120 V, 50–60 Hz
150 W
Operating ambient temperature: 41°F to 104°F (5°C to 40°C)
Operating ambient humidity:
10% to 90% (no condensation)
Weight:
35.2 Ibs (16 kg)
Dimensions (W×H×D):
16-3/4×6-15/16x16-3/8 inches
(424×175×415 mm)
Recording format:
DVCPRO format
Recording tracks:
Digital video
Time code
Recorded in sub-code area
Digital audio 2 channels
Cue Track
1 track
Control (CTL) 1 track
Tape speed:
33.820 mm/sec
Recording time:
123 minutes (with AJ-P123LP)
63 minutes (with AJ-P63MP)
Tape:
1/4-inch thin magnetic layer metal tape
FF/REW time:
Less than 3 min (with AJ-P123LP)
Less than 2 min (with AJ-P63MP)
Search speed:
0 to ±60× normal speed (color)
Digital slow motion:
+0.75× normal speed in + direction
–0.43× normal speed in – direction
Editing accuracy:
±0 frame (using time code)
Tape timer accuracy:
±1 frame (using continuous CTL signal)
Servo lock time:
Less than 0.5 sec. (color framing/
standby ON)
VIDEO
(Digital video)
Sampling frequencies:
Y: 13.5 MHz/P B , P R : 3.375 MHz
Quantizing:
8 bits
Error correction:
Reed-Solomon product code
(Digital IN/analog component OUT)
Video bandwidth:
Y: 30 Hz to 5.5 MHz (±1.0 dB)
P
B , P R : 30 Hz to 1.0 MHz (±1.0 dB)
S/N ratio:
Better than 60 dB
K factor:
Less than 2%
(Analog component IN/component OUT)
Video bandwidth:
Y: 30 Hz to 5.5 MHz (–1.5 dB to ±1.0 dB)
P
B , P R : 30 Hz to 1.0 MHz
(–2.0 dB to ±1.0 dB)
S/N ratio:
Better than 55 dB
K factor:
Less than 2%
(Analog composite IN/composite OUT)
Video bandwidth:
Y/C delay:
K factor:
(Video input connector)
Analog component input:
Analog composite input:
S VIDEO input:
Reference input:
Serial digital component input
(option):
Y: 30 Hz to 4.5 MHz (–1.5 dB to ±1.0 dB)
Better than 20 ns
Less than 3%
BNC×3 (Y, P
B , P R )
Y: ±1.0 Vp-p, 75 Ω
P B , P R : 0.486/0.7 Vp-p switchable, 75 Ω
(75% color bar, 7.5% setup)
BNC×2, loop-through, 75
Ω on/off
S terminal (4-pin)×1
Y: ±1.0 Vp-p, 75 Ω
C: 0.286 Vp-p (burst), 75 Ω
Analog composite
BNC×2, loop-through, 75 Ω on/off
Complies with SMPTE259M-C standard,
BNC×2, active through
(Video output connector)
Analog component output:
Analog composite output:
S VIDEO output:
Serial digital component output
(option):
(Video signals adjustment)
Video output gain:
Video output chroma gain:
Video output hue:
Video output setup:
Video output sync phase:
Video output SC phase:
AUDIO
(Digital audio)
Sampling frequencies:
Quantizing:
Frequency response:
Dynamic range:
Distortion:
Crosstalk:
Wow & flutter:
Headroom:
De-emphasis:
(Cue track)
Frequency response:
(Audio input connector)
Analog input (CH1/CH2):
BNC×3 (Y, P B , P R )
Y: ±1.0 Vp-p, 75 Ω
P B , P R : 0.486/0.7 Vp-p switchable, 75 Ω
(75% color bar, 7.5% setup)
BNC×3
Video1/video2/video3 (superimpose
on/off)
S terminal (4-pin)×1
Y: ±1.0 Vp-p, 75 Ω
C: 0.286 Vp-p (burst), 75 Ω
Complies with SMPTE259M-C standard,
BNC×3
±3 dB
±3 dB
±30°
±15 IRE
±2
µ
s
±180°
Control from ENCODER
REMOTE connector
48 kHz
16 bits
20 Hz to 20 kHz (–1.0 dB to +0.5 dB)
Better than 86 dB (1 kHz, emphasis OFF,
“A” weighted)
Less than 0.1% (1 kHz, emphasis OFF,
standard level)
Less than –80 dB (1 kHz, between
2 channels)
Below measurable limits
20 dB
T1=50 µT2=15 µs (on/off automatic)
300 Hz to 6 kHz ±3 dB
XLR×2, 600 Ω/high impedance selectable,
+4/0/–20/–60 dBu
Digital input (CH1/CH2) (option): BNC×1, AES/EBU format
Serial digital input (option):
Complies with SMPTE259M-C, 272M
standard (BNC)
(Audio output connector)
Analog output (CH1/CH2):
Digital output (CH1/CH2)
(option):
Serial digital output (option):
Monitor output:
Headphones:
XLR×2, low impedance, +4/0/–20 dBu
BNC×1, AES/EBU format
Complies with SMPTE259M-C, 272M
standard (BNC)
Phono×1, 600
Ω , –8 dBV
Variable level, 1/4" phone, 8 Ω
Other input/output connector
Time code input:
BNC×1, 0.5 to 8 Vp-p
Time code output:
BNC×1, 2.0 Vp-p
RS-422A input/output: D-sub 9-pin, RS-422A interface
RS-232C (option): D-sub 25-pin, RS-232C interface
Encoder remote:
D-sub 15-pin
Weight and dimensions when shown are approximately.
Specifications are subject to change without notice.
