Panasonic AJ-D650 - Technical Specifications; Connector Signals and Interface Specs

Connector signals
VIDEO IN
SERIAL IN (DIGITAL) BNC×2
Active through (Option)
Y, PB, PR (ANALOG) BNC×3
VIDEO IN
BNC×2
Loop-through, 75 Ω
termination
switch provided
REF VIDEO IN
BNC×2
Loop-through, 75 Ω
termination
switch provided
S1-VIDEO IN 4-pin × 1
VIDEO OUT
SERIAL OUT (DIGITAL) BNC × 3
(Option)
Y, PB, PR (ANALOG)
BNC × 3
VIDEO OUT
BNC × 3
S1-VIDEO IN
4-pin × 1
AUDIO IN
SERIAL IN (DIGITAL)
BNC × 2
(Option)
Pin No.
Signal
AUDIO IN (DIGITAL)
BNC × 1 CH1/CH2 AES/EBU format
1
(Option)
2
GND
HOT
AUDIO IN (ANALOG)
XLR × 2
CH1, CH2
3
COLD
TIME CODE IN
BNC × 1
AUDIO OUT
SERIAL OUT (DIGITAL) BNC × 3
(Option)
AUDIO OUT (DIGITAL) BNC × 1
CH1/CH2 AES/EBU format
(Option)
AUDIO OUT (ANALOG) XLR × 2
CH1, CH2
TIME CODE OUT
BNC × 1
MONITOR OUT
PHONO × 1
HEADPHONES (front) 1/4" phone × 1
RS-422A REMOTE (9P)
RMOTE
Pin No. Signal Pin No. Signal Pin No.
Signal
1
FRAME GROUND 4
RECEIVE COMMON
7
TRANSMIT B
2 TRANSMIT A
58 RECEIVE A
3 RECEIVE B
6 TRANSMIT COMMON
9
FRAME GROUND
–49–
