Setup Menu: Menu List
Registers functions to the input connectors and registers statuses to the output connectors of the PARALLEL REMOTE connec-
tor.
_ is the factory default setting.
PARALLEL PORT
Item Settings and brief function description FREQ indications
PORT1
REC BUTTON: Performs the same operation as the [REC] button.
REC+PLAY BUTTON:
Performs the same operation as simultaneously pressing the [REC] and [PLAY]
buttons.
PLAY BUTTON: Performs the same operation as the [PLAY] button.
STILL/PAUSE BUTTON: Performs the same operation as the [PAUSE] button.
FF BUTTON: Performs the same operation as the [FF] button.
STOP BUTTON: Performs the same operation as the [STOP] button.
REW BUTTON: Performs the same operation as the [REW] button.
SHTL BUTTON: Performs the same operation as the [SEARCH] button.
AUDIO LVL REC BUTTON: Performs the same operation as the [AUDIO LEVEL-REC] button.
AUDIO LVL PB BUTTON: Performs the same operation as the [AUDIO LEVEL-PB] button.
REMOTE BUTTON: Performs the same operation as the [REMOTE] button.
COUNTER BUTTON: Performs the same operation as the [COUNTER] button.
RESET BUTTON: Performs the same operation as the [RESET] button.
PRESET BUTTON: Performs the same operation as the [TC PRESET] button.
DISPLAY BUTTON: Performs the same operation as the [DISPLAY] button.
USER1 BUTTON: Performs the same operation as the [USER1] button.
USER2 BUTTON: Performs the same operation as the [USER2] button.
USER3 BUTTON: Performs the same operation as the [USER3] button.
USER4 BUTTON: Performs the same operation as the [USER4] button.
USER5 BUTTON: Performs the same operation as the [USER5] button.
USER6 BUTTON: Performs the same operation as the [USER6] button.
UP BUTTON: Performs the same operation as the up cursor button.
DOWN BUTTON: Performs the same operation as the down cursor button.
LEFT BUTTON: Performs the same operation as the left cursor button.
RIGHT BUTTON: Performs the same operation as the right cursor button.
SET BUTTON: Performs the same operation as the [SET] button.
THUMBNAIL BUTTON: Performs the same operation as the [THUMBNAIL] button.
SHIFT BUTTON: Performs the same operation as the [SHIFT] button.
MENU BUTTON: Performs the same operation as the [MENU] button.
EXIT BUTTON: Performs the same operation as the [EXIT] button.
KEY INHIBIT: Prohibits/allows operation of the front panel.
TEXT MEMO: Adds a text memo.
MARKER: Adds a shot mark.
ONE CLIP PLAY: Functions as the ONE CLIP PLAY button.
SLOT CLIPS:
Switches the thumbnail screen display between “SELECTED CLIPS” > “SLOT1” > “SLOT2” >.
SLOT SEL: Changes the P2 card slot for recording.
REC MEDIA: “REC/PB SETUP” - Changes the “REC MEDIA” settings.
TCG MODE: Changes the “TCG MODE” settings.
UBG MODE: Changes the “UBG MODE” settings.
RUN MODE: Changes the “RUN MODE” settings.
EXT TC SEL: Changes the “EXT TC SEL” settings.
VIDEO IN SEL:Changes the “INPUT SEL” (VIDEO) settings.
INT SG: “VIDEO” - Changes the “INT SG” settings.
AUDIO IN SEL: Changes the “INPUT SEL” (AUDIO) settings.
MONITOR CH SEL: Changes the “MONITOR CH SEL” settings.
LEVEL METER: Changes the “LEVEL METER” settings.
WFM TYPE: Changes the “WFM TYPE” settings.
PORT2 The settings are the same as PORT1. The factory default setting is STOP BUTTON.
PORT3 The settings are the same as PORT1. The factory default setting is FF BUTTON.
PORT4 The settings are the same as PORT1. The factory default setting is REW BUTTON.
PORT5 The settings are the same as PORT1. The factory default setting is REC BUTTON.
PORT6 The settings are the same as PORT1. The factory default setting is SHTL BUTTON.
PORT7 The settings are the same as PORT1. The factory default setting is USER1 BUTTON.
