Menu Item Adjustment setting range Initial value
Items recorded on SD memory cards
Setting1 HD-SDI2 OUT MAIN, VF, RET VF
HD-SDI2 Power ACTIVE, SAVE ACTIVE
AUX I/O RET
Y IN, PMT2 OUT, VBS OUT, D1 OUT RET Y IN
TRUNK1 RS4
22, RS232C RS422
TRUNK2 RS422, RS232C RS422
5600K OFF, ON OFF
Setting
2
HND GRIP RET A, B, PTT A
HND GRIP PTT PTT, A, B PTT
HND Lens VTR VTR, A, B, PTT B
HND Lens RET A, B A
STD Lens RET1 A, B A
STD Lens RET
2 A, B B
EXT RET 1 A, B A
EXT RET
2 A, B B
EXT RET
3 A, B B
Setting
3
RET1 ID Enables a name (5 characters) to be set. RET1.
RET
2 ID Enables a name (5 characters) to be set. RET
2.
RET
3 ID Enables a name (5 characters) to be set. RET
3.
RET4 ID Enables a name (5 characters) to be set. RET4.
Gain SW LOW –6 dB to
36 dB (in 3 dB increments) 0 dB
Gain SW MID –6 dB to
36 dB (in 3 dB increments) 6 dB
Gain SW HIGH –6 dB to
36 dB (in 3 dB increments) 12 dB
ID Character Enables a name (10 characters) to be set. —
Setting4
User SW1 RET A, RET B
, PTT, DISP, MARK OFF (*2) RET A
User SW
2 RET A, RET B, PTT, DISP, MARK OFF PTT
User SW
3 RET A, RET B, PTT, DISP, MARK OFF PTT
User B/U
RET A, RET B, PTT, DISP, MARK OFF,
LENS EXT
PTT
Back Light 1 to 70 2
0
RET Mode NORM, TOGGLE, SEQ. NORM
Lens I/F Analog, Serial Analog
B/U Lens PORTABLE, BOX BOX
Rear ROP VR CAM, CCU CAM
!LED
Gamma Off OFF, ON OFF
Shutter OFF, ON OFF
Extender OFF, ON OFF
MONI OUT OFF, ON OFF
FAN Off OFF, ON OFF
Master Gain OFF, ON OFF
Black Gamma OFF, ON OFF
7"VF
VF FAN Speed NORM, LOW NORM
Peak Slice OFF, LOW, MID, HIGH OFF
Peak FREQ 8 MHz, 15 MHz 8 MHz
INCOM Set.1 INC1 MIC Type DYN, ECM, CBN DYN
INC1 MIC Gain –1
2 dB to +12 dB (in 3 dB increments) 0 dB
INC1 MIC Power OFF, ON OFF
INC1 Side Tone OFF
, –36 dB to 0 dB (in 3 dB increments) OFF
INC1 PGM MIX ON, OFF ON
INC1 ENG/PROD ENG, PROD ENG
INC1 to CCU OFF, ON ON
INCOM Set.
2 INC2 MIC Type DYN, ECM, CBN DYN
INC
2 MIC Gain –12 dB to +12 dB (in 3 dB increments) 0 dB
INC
2 MIC Power OFF, ON OFF
INC
2 Side Tone OFF, –36 dB to 0 dB (in 3 dB increments) OFF
INC
2 PGM MIX ON, OFF ON
INC
2 ENG/PROD ENG, PROD ENG
CRANE MIC Gain –1
2 dB to +12 dB (in 3 dB increments) 0 dB
CRANE Side Tone OFF
, –36 dB to 0 dB (in 3 dB increments) OFF
CRANE ENG/PROD ENG, PROD ENG
CRANE to CCU OFF, ON ON
MIC Gain MIC1 Gain 2
0 dB, 40 dB, 60 dB 60 dB
MIC1 AMP –
20 dB to 20 dB (in 1 dB increments) 0 dB
MIC2 Gain 20 dB, 40 dB, 60 dB 60 dB
MIC
2 AMP –20 dB to 20 dB (in 1 dB increments) 0 dB
Table of adjustment setting ranges
*2: DISP: At the DISP setting, the character display is forcibly set to OFF while the user switch is pressed.
MARK OFF: At the MARK OFF setting, ZONE, SAFETY, CURSOR, CENTER and WFM are forcibly set to OFF while the user switch
is pressed.
