38
Table of adjustment setting ranges
Maintenance
Menu Item Adjustment setting range Initial value
Date / Time (*4) Present (Current date/time)
Adjust NO?, YES?
1
2H/24H 24H, 12H 24H
Date YY 00 to 99 00
Date MM 01 to 1
2 01
Date DD 01 to
31 01
Date aaa MON, TUE, WED, THU, FRI, SAT, SUN MON
Time HH 00 to
23 00
Time NN 00 to 59 00
Time SS 00 to 59 00
Set Exe NO?, YES?
Reset NO?, YES?
SD Card Mode FORMAT, LOAD, STORE LOAD
File No. 1 to 8 1
EXECUTE NO?, YES?
Scene File Mode LOAD, STORE LOAD
File No.
OFF, 1 to 8 (when LOAD is selected)
1 to 8 (when STORE is selected)
1
EXECUTE NO?, YES?
Lens File Mode LOAD, STORE LOAD
File No.
OFF, 01 to 16 (when LOAD is selected)
01 to 16 (when STORE is selected)
01
File Name
(Filename)
Enables a name (8 characters) to be set.
EXECUTE NO?, YES?
Lens Edit EXT (Lens magnification display)
File (Filename)
Gain R –100 to +100 0
Gain G –100 to +100 0
Gain B –100 to +100 0
Flare R –100 to +100 0
Flare G –100 to +100 0
Flare B –100 to +100 0
W H SAW R/G/B –100 to +100 0
W H PARA R/G/B –100 to +100 0
W V SAW R/G/B –100 to +100 0
W V PARA R/G/B –100 to +100 0
Store? NO?, YES?
Cancel? NO?, YES?
Iris Cont.
Auto Iris
OFF, ON
When only the camera is used, Auto Iris is ON.
OFF
When only the camer
a
is used, Auto Iris is ON.
Window Select 1 to 8 (*5) 1
Iris Level 0 to 100 50
Peak Ratio 0 to 100 60
A.Iris Range NORMAL, (
3/4), (2/4), (1/4) NORMAL
A.Iris Speed 1 to
25 15
LensExtComp.SW NORMAL, ON NORMAL
LensExtComp.LVL –40 to +40 0
Close End SW OFF, ON OFF
Close EndOffset –
20 to +20 0
*4: If the date and time have not been set properly, the time may not be updated properly.
The clock has an error which may cause it to gain or lose up to one minute per month.
*5: The types of windows which can be selected are as shown in the figure below.
