Panasonic AK-HRP1000G

Specifications
General
Power supply
12 V DC ( ) (Power supply from camera: 10 V - 16 V DC)
42 V - 57 V DC ( ) (PoE power supply)
Power consumption
0.51 A (Power supply from camera: 10 V - 16 V DC)
0.15 A (PoE power supply)
indicates safety information.
Camera/CCU control
Control signals (camera, CCU control)
Power supply 16 V DC (when CCU connected) *
1
, 12 V DC (when camera connected) *
1
Maximum cable length
When camera connected: 20 m (65.7 ft)
When CCU connected: 50 m (164 ft)
Operating temperature 0°C to 40°C (32°F to 104°F)
Storage temperature -20°C to 60°C (-4°F to 140°F)
Humidity 90% or less
Dimensions (Width×Height×Depth): 102 mm × 385 mm × 113 mm (4 inches × 15-3/16 inches × 4-7/16 inches)
Weight
Approx. 1.7 kg (3.75 lb)
*1: Can be provided from CCU
- 141 -
Specifications
