Panasonic CF-R1 Series

43
Modem
Modem
Do not enter either the standby or hibernation mode during communica-
tions.
NOTE
Connecting the Internal Modem with a Telephone Jack
1 Connect the computer and the telephone jack using a mo-
dem telephone cable
Open the modem cover, position the cable so that the tab matches the port
( ), and insert the cable.
2 Set the modem
Windows 2000
1 Select [Edit] in [Start] - [Settings] - [Control Panel] - [Phone and Modem Op-
tions] - [Dialing Rules], then select the location from which you will be dialing
in [Country/region].
2 Input the necessary information (items such as the country, area code, etc.),
select [OK], then select [OK].
Windows XP
1 Select [Edit] in [start] - [Control Panel] - [Printers and Other Hardware] - [Phone
and Modem Options] - [Dialing Rules], then select the location from which
you will be dialing in [Country/region].
2 Input the necessary information (items such as the country, area code, etc.),
select [OK], then select [OK].
CAUTION
Do not use the PBX internal phone lines inserted in company offices.
Doing so may lead to a fire or electric shock.
It is not possible to connect the modem to any of the following lines.
· Internal home phones
· Intercoms
Be sure to connect the modular cable into the modem port, not into the
LAN port.
