CU-C18BBP5
Ref. No. Part Name & Description Qty Part No.
1 BASE PAN ASS’Y 1 CWD50K2076B
2 COMPRESSOR 1 2K32C225CUA
3 ANTI-VIBRATION BUSHING 4 CWH50055
4 NUT FOR COMP. MOUNT. 3 CWH4582065
5 CONDENSER COMPLETE 1 CWB32C1241
6 TUBE ASS’Y (CAPILLARY TUBE) 1 CWH35K029B
7 CONDENSER SIDE PLATE 1 CWE04111B
8 ACCUMULATOR 1 CWB13K1002
9 3-WAYS VALVE 1 CWB011125
10 STRAINER 1 CWB11025
11 3-WAYS VALVE 1 CWB01364
12 SOUND-PROOF BOARD ASS’Y 1 CWH151036
13 SOUND PROOF MATERIAL-COMP 1 CWG302047
14 PIPE SENSOR (COIL) 1 CWA501043
15 SPRING FOR SENSOR 2 CWH711010
16 CABINET REAR PLATE 1 CWE02096B
17 CONTROL BOARD 1 CWH10K1025
18 COMPRESSOR RELAY 1 CWA4000088
19 TERMINAL BOARD ASS’Y 1 CWA28K234
20 CAPACITOR-FAN MOTOR 1 DS461255QP-A (2.5µF / 460v)
21 CAPACITOR-COMPRESSOR 1 DS371506CPNA (50µF / 370v)
22 ELECTRONIC CONTROLLER 1 CWA73C1195
23 TRANSFORMER 1 CWA401029
24 CURRENT TRANSFORMER BOARD 1 CWA742592
25 CONTROL BOARD COVER 1 CWH131151A
26 TERMINAL COVER 1 CWH171012
27 BRACKET-FAN MOTOR 1 CWD54238
28 SCREW-BRACKET FAN MOTOR 4 CWH55027
29 FAN MOTOR 1 CWA921141
30 SCREW-FAN MOTOR 4 CWH55252
31 PROPELLER FAN 1 CWH00K1001
32 NUT for PROPELLER FAN 1 CWH56060
33 P.FAN AIR GUIDER PLATE 1 CWE06172B
34 CABINET TOP PLATE COMPLETE 1 CWE03101B
35 CABINET FRONT PLATE 1 CWE06K034B
36 HANDLE 3 CWE16000E
37 LEADWIRE-COMPRESSOR 1 CWA67C4318
38 INSTALLATION INSTRUCTION 1 CWF612321
101
