15.2. PERFORMANCE DATA
CS-A18BD3P/CU-A18BBP5, CS-C18BD3P/CU-C18BBP5
Model
COOLING PERFORMANCE
Ambient Temperature Air Entering Condenser (°C D.B.)
Return 25°C 30°C 35°C 40°C 45°C
Air TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
17 6.84 5.98 2.09 6.58 5.88 2.25 6.25 5.76 2.39 5.86 5.51 2.55 5.40 5.07 2.68
23 19 7.17 5.19 2.25 6.91 5.13 2.39 6.58 5.01 2.55 6.25 4.88 2.71 5.86 4.68 2.83
22 7.76 4.02 2.49 7.50 4.02 2.62 7.17 3.98 2.78 6.84 3.93 2.91 6.44 3.82 3.06
17 6.80 5.95 2.09 6.54 5.84 2.25 6.21 5.72 2.39 5.82 5.47 2.55 5.36 5.04 2.68
25 19 7.12 5.16 2.25 6.86 5.10 2.39 6.54 4.98 2.55 6.21 4.85 2.71 5.82 4.65 2.83
22 7.72 3.99 2.49 7.46 4.00 2.62 7.12 3.95 2.78 6.80 3.90 2.91 6.41 3.80 3.06
17 6.76 5.91 2.09 6.50 5.81 2.25 6.18 5.69 2.39 5.79 5.44 2.55 5.33 5.01 2.68
27 19 7.09 5.13 2.25 6.83 5.07 2.39 6.50 4.95 2.55 6.18 4.82 2.71 5.79 4.63 2.83
22 7.67 3.96 2.49 7.41 3.97 2.62 7.09 3.93 2.78 6.76 3.88 2.91 6.37 3.77 3.06
17 6.72 5.88 2.09 6.46 5.78 2.25 6.15 5.66 2.39 5.76 5.41 2.55 5.30 4.98 2.68
29 19 7.05 5.10 2.25 6.79 5.05 2.39 6.46 4.92 2.55 6.15 4.79 2.71 5.76 4.60 2.83
22 7.63 3.95 2.49 7.37 3.95 2.62 7.05 3.91 2.78 6.72 3.86 2.91 6.33 3.75 3.06
17 6.67 5.83 2.09 6.42 5.73 2.25 6.09 5.61 2.39 5.71 5.37 2.55 5.26 4.94 2.68
32 19 6.99 5.06 2.25 6.73 5.00 2.39 6.42 4.89 2.55 6.09 4.76 2.71 5.71 4.57 2.83
22 7.57 3.91 2.49 7.32 3.92 2.62 6.99 3.88 2.78 6.67 3.82 2.91 6.29 3.73 3.06
Legend : BF Bypass Factor 0.20 SHC Sensible Heat Capacity TC Total Cooling Capacity
CAPACITY SELECTION NOTES
(1) The table above is based on unit nominal evaporator airflow,
correction factor must therefore be applied for selections
away from this condition.
COOLING CORRECTION FACTORS
EVAP. AIR FLOW m
3
/ min (l/s) 14 (233) 17 (283) 20 (333) 23 (383)
SHC Sensible Heat Capacity 0.86 0.93 1 1.08
TC Total Cooling Capacity 0.92 0.96 1 1.05
