●HEATING CAPACITY CURVE
<Precautions on using capacity and electrical
characteristics curves>
•
• •
• Heating capacity when the unit is frosted over or while
being defrosted will vary depending on outdoor
temperature (´CW8) and the amount c frost. Heating
capacity performance must be compensated because it
does not take into account the capacity drop incurred
when the unit is frosted over and while it is being
defrosted. Therefore, to obtain the integral heating
capacity in consideration 01 overfrosting and defrost
operations. Heating capacity must be multiplied by the
compensation coefficient below.
•
• •
• Heating capacity compensation coefficient for heating in
frosted situations.
●
●●
●HEATING POWER CONSUMPTION CURVE
15.3. HEATING CAPACITY CURVE, HEATING POWER CONSUMPTION
CURVE (HEAT PUMP MODEL ONLY)
●
●●
●RATED HEATING CAPACITY, RATED HEATING POWER CONSUMPTION
MODEL NAME RATED HEATING STANDARD
CAPACITY (kW) POWER CONSUMPTION (kW)
CS-A24BD3P/CU-A24BBP5 7.10 2.50
CS-A28BD3P/CU-A28BBP5 7.75 2.61
CS-A28BD3P/CU-A28BBP8 7.75 2.40
CS-A34BD3P/CU-A34BBP5 11.20 3.55
CS-A34BD3P/CU-A34BBP8 11.20 3.40
CS-A43BD3P/CU-A43BBP8 14.20 3.90
CS-A50BD3P/CU-A50BBP8 15.70 5.09
35
