Panasonic CS-A18BD3P

ELECTRICAL DATA (50Hz)
4 SPECIFICATION (COOLING ONLY TYPE )
4.1 CS-A18BD3P / CU-C18BBP5
ITEM / MODEL Indoor Unit Outdoor unit
Main Body CS-A18BD3P CU-C18BBP5
Cooling Capacity kW 5.00
(BTU/h) (17,100)
Refrigerant Charge-less m 10
Standard Air Volume for High m
3
/min Hi 17 -
Medium and Low Speed cfm Hi 600 -
External Static Pressure mmAq 7 -
Pa 69
Air Inlet Backward Suction Rear sided Suction
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 270 x (780 + 100) x 650 685 x 800 x 300
Net Weight kg (lbs) 34 (75) 52 (115)
Piping Connection Refrigerant Gas mm (inch) O.D Ø 12.7 (1/2) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor Type, Number of Set - Hermetic-1 (Rotary), 1
Starting
Method
- Direct on-line starting
Motor Type - 2-pole single phase induction
motor
Input kW - Cool/2.31
Rated Output kW - 1.5
Fan Type, Number of Set Sirocco fan-2 Prop. fan-1
Air Volume Control Three-Step and Auto mode -
(Remote Control)
Motor Type 4-pole single phase induction motor 6-pole single phase induction
motor
Input kW 0.15 0.11
Rated Output kW 0.085 0.045
Air-heat exchanger Louvre-fin type Louvre-fin type
Refrigerant Control Capillary tube Capillary tube
Refrigerant oil (Charged) L - M60 (0.67)
Refrigerant (Charged) kg (oz) - R-22 1.6 (56)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal thermostat for F.M, Crankcase
heater, High pressure switch, Current Transformer
Noise Level (Sound Pressure) dB (A) Hi 37 Lo 33 Hi 54
Power level dB Hi 52 Lo 48 Hi 67
1. Cooling capacities are based on indoor temp. 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air temp. 35°C
D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
MODEL / ITEM CS-A18BD3P/CU-C18BBP5
Condition by JIS B 8616
Volts V 220 230 240
Phase Single Single Single
Input Power kW Cool 1.95 1.95 1.95
Running Current A Cool 9.0 8.9 8.8
Starting Current A 38 40 42
Power Factor % Cool 98 95 92
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
