14 COMPONENT SPECIFICATION
Compressor
Model Heat pump model 50Hz CU-A18BBP5
Cooling only model 50Hz CU-C18BBP5
Compressor Model 2K32C225CUA
Compressor Type No. of Cylinders ROTARY
1
Revolution r/min 2,900
Piston Displacement m
3
/h 7.27
Motor Type kW
Starting Method Direct on-line Starting
Rated Output 1.5
Poles 2
Insulation Class E
Oil Type M60
Charge L 0.67
Condenser
Models Heat pump model CU-A18BBP5
Cooling only model CU-C18BBP5
Tube Material
Outer Diameter mm 9.52
Thickness mm 0.3
Row 2
No. of Tubes/Row 34
Fin Material
Thickness mm 0.105
Fin Pitch No./inch 14
Fin Surface AX-Louvre fin
Total Face Area m
2
0.61
Fan
Type
No.of unit 1
Fan Motor
Starting Method
Rated Output kW 0.045
Poles 4
Phase Single-Phase
Insulation Class E
31
