15 Replacement Parts List (Indoor Unit)
15.1. CS-E15DB4EW CS-E18DB4EW CS-E21DB4ES
REF. NO. PARTS NAME & DESCRIPTION QTY CS-E15DB4EW CS-E18DB4EW CS-E21DB4ES REMARKS
1 BASE PAN ASS’Y 1 CWD52K1100
← ←
2 INNER POLYSTYRENE COMPLETE 1 CWG07C1047
← ←
3 CABINET SIDE PLATE ASS’Y 1 CWE041121
← ←
4 CABINET SIDE PLATE ASS’Y 1 CWE041122
← ←
5 LEAD WIRE - FAN MOTOR 1 CWA67C5136
← ←
6 FAN MOTOR 1 EHDS50A40AC
← ←
O
7 ANTI - VIBRATION BUSHING 3 CWH501065
← ←
8 CORD HOLDER 1 CWD741024
← ←
9 SCREW - FAN MOTOR 3 CWH7080300
← ←
11 TURBO FAN 1 CWH03K1022
← ←
12 NUT for TURBO FAN 1 CWH561042
← ←
13 SP WASHER 1 XWA8
← ←
14 WASHER 1 XWG8H22
← ←
15 EVAPORATOR COMPLETE 1 CWB30C1668
←
CWB30C1526
16 FLARE NUT (1/2”) 1 CWT251032
← ←
17 HEATPROOF TUBE 1 CWG021024
← ←
18 HEATPROOF TUBE 1 CWG021064
← ←
19 FLARE NUT (1/4”) 1 CWT251030
← ←
21 PIPE COVER 1 CWD93C1050
← ←
22 SENSOR - EVAPORATOR 1 CWA50C2274
← ←
23 HOLD SENSOR 1 CWH32143
← ←
24 EVAPORATOR SUPPORTER 3 CWD911529A
← ←
25 TUBE ASS’Y (CAPIL. TUBE) 1 CWT07K1188
← ←
26 DRAIN PUMP COMPLETE 1 CWB53C1015
← ←
27 PANEL DRAIN PUMP ASS’Y 1 CWD93K1008
← ←
28 DRAIN PUMP 1 CWB532043
← ←
29 ANTI - VIBRATION BUSHING 3 CWH501080
← ←
30 FLOAT SWITCH - DRAIN PUMP 1 CWA121215
← ←
31 FLEXIBLE PIPE 1 CWH85C1033
← ←
32 DRAIN NOZZLE 1 CWH411011
← ←
33 DRAIN HOSE HEAT INSULATION 1 CWG321050
← ←
35 DRAIN PAN - COMPLETE 1 CWH40C1034
← ←
36 DRAIN PLUG 1 CWB821008
← ←
37 AIR GUIDER BLOWER WHEEL 1 CWD321058
← ←
38 CONTROL BOARD CASING 1 CWH10K1048
← ←
39 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1778 CWA73C1779 CWA73C1780 O
40 SPACER 6 CWH541026
← ←
41 TRANSFORMER 1 CWA40C1030
← ←
43 TERMINAL BOARD - (3 PIN) 1 CWA28K1076
← ←
O
44 LEADWIRE-AIR TEMP. SENSOR 1 CWA67C5139
← ←
O
47 CONTROL BOARD COVER 1 CWH13C1100
← ←
48 ACCESSORY COMPLETE 1 CWH82C1270
← ←
48A HEATPROOF TUBE 1 CWG021025
← ←
51 WIRELESS REMOTE CONTROL COMPLETE 1 CWA75C2610
← ←
O
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
82
CS-E15DB4EW CU-E15DBE / CS-E18DB4EW CU-E18DBE / CS-E21DB4ES CU-E21DBE
