15.2. CZ-BT20E (Front Grille Complete)
REF. NO. PART DESCRIPTION QTY PART NO.
1 FRONT GRILLE - COMPLETE 1 CWE11C3105
2 FRONE - FRONT GRILLE CO. 1 CWE11C3353
4 A.S MOTOR DC SINGLE 12V 250 OHM 2 CWA981105
5 BRACKET - A.S.MOTOR 1 CWD932522
6 VANE 4 CWE241159
7 SHAFT 6 CWH631038
8 SHAFT 2 CWH631045
9 CONNECTOR - SHAFT 4 CWH081007
10 BEARING 6 CWH641008
11 LEAD WIRE - A.S.MOTOR 1 CWA67C5117
12 PLATE COVER FOR A.S.MOTOR 1 CWD911459
13 PLATE COVER FOR CONNECTING SHAFT 2 CWD911460
14 PLATE COVER FOR END SHAFT 1 CWD911461
21 ELECTRONIC CONT. (RECEIVER & INDICATOR) 1 CWA743610
22 LEAD WIRE - COMPLETE 1 CWA67C5576
24 INTAKE GRILLE 1 CWE221131
28 LEVER ARM 2 CWH651029
29 AIR FILTER 1 CWD001142
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
83
CS-E15DB4EW CU-E15DBE / CS-E18DB4EW CU-E18DBE / CS-E21DB4ES CU-E21DBE
