13.2. Sensible Capacity Chart
●
CS-E15DTEW CU-E15DBE
Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 4.12 3.12 1.18 3.85 2.99 1.27 3.58 2.88 1.36 3.25 2.73 1.47
19.0°C 4.15 1.29
19.5°C 4.52 3.27 1.20 4.22 3.14 1.30 3.93 3.02 1.39 3.57 2.88 1.49
22.0°C 4.93 3.39 1.23 4.60 3.26 1.32 4.28 3.14 1.41 3.89 3.00 1.52
●
CS-E18DTEW CU-E18DBE
Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 4.96 3.76 1.52 4.64 3.61 1.64 4.31 3.47 1.75 3.92 3.29 1.89
19.0°C 5.00 1.66
19.5°C 5.45 3.94 1.55 5.09 3.78 1.67 4.74 3.64 1.78 4.31 3.47 1.92
22.0°C 5.94 4.08 1.58 5.55 3.93 1.70 5.16 3.79 1.81 4.69 3.61 1.96
●
CS-E21DTES CU-E21DBE
Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.75 4.36 1.77 5.38 4.18 1.90 5.00 4.02 2.03 4.55 3.82 2.19
19.0°C 5.80 1.93
19.5°C 6.32 4.57 1.80 5.90 4.39 1.94 5.49 4.22 2.07 4.99 4.02 2.23
22.0°C 6.88 4.74 1.83 6.43 4.55 1.97 5.99 4.39 2.11 5.44 4.19 2.28
TC - Total Cooling Capacity (kW) Indoor 27°C/19°C
SHC - Sensible Heat Capacity (kW) Outdoor 35°C/24°C
IP - Input Power (kW)
75
CS-E15DTEW CU-E15DBE / CS-E18DTEW CU-E18DBE / CS-E21DTES CU-E21DBE
