15 Replacement Parts List (Indoor Unit)
15.1. CS-E15DTEW CS-E18DTEW CS-E21DTES
REF NO. DESCRIPTION & NAME QTY. CS-E15DTEW CS-E18DTEW CS-E21DTES REMARKS
1 CHASSY COMPLETE 1 CWD50C1419
← ←
2 FAN MOTOR 1 CWA921158
← ←
O
3 SUPPORTER FAN MOTOR 2 CWD932270
← ←
4 BLOWER WHEEL ASSY 2 CWH01K1014
← ←
5 AIR GUIDER B.W. 2 CWD321046
← ←
6 CONTROL BOARD ASSY 1 CWH10K1055
← ←
7 FLARE NUT (1/2”) 1 CWT251032
← ←
8 TERMINAL BOARD ASSY 1 CWA28K1036
← ←
O
10 ELECTRONIC CONTROLLER 1 CWA73C1771 CWA73C1772 CWA73C1773 O
11 SENSOR ASSY COMP 1 CWA50C2157
← ←
O
12 LEAD WIRE FAN MOTOR 1 CWA67C4431
← ←
13 LEAD WIRE FAN MOTOR 1 CWA67C4474
← ←
14 EVAPORATOR 1 CWB30C1663 CWB30C1661 CWB30C1656
15 SUPPORTER TUBE ASSY 1 CWD932259
← ←
16 FLARE NUT (1/4”) 1 CWT25086
← ←
17 DRAIN PAN COMPLETE 1 CWH40C1023
← ←
18 TAP DRAIN TRAY 1 CWH401031
← ←
19 DISCHARGE GRILLE COMPLETE 1 CWE20C2223
←
CWE20C2189
20 DISCHARGE GRILLE 1 CWE201046
← ←
21 VANE-AIR SWING 1 CWE241124
← ←
22 CONNECTING BAR 2 CWE261052
← ←
23 CONNECTING BAR 2 CWE261053
← ←
24 VANE 14 CWE241126
← ←
O
25 AIR SWING MOTOR 1 CWA981085
← ←
O
26 INDICATOR COMP. 1 CWE39C1128
← ←
28 CONTORL BOARD CASING ASSY 1 CWH13K1015
← ←
31 INTAKE GRILLE COMPLETE 1 CWE22C1185
← ←
32 AIR FILTER 2 CWD001088
← ←
33 REMOTE CONTROL COMPLETE 1 CWA75C2610
← ←
O
36 DRAIN HOSE 1 CWH85284
← ←
37 INSTALLATION HOLDER 1 CWH361018
← ←
38 ACCESSORY COMPLETE 1 CWH82C1286
← ←
39 FULCRUM 3 CWH621030
← ←
40 FRONT GRILLE COMPLETE 1 CWE11C3209
← ←
41 STRING COMPLETE 1 CWH84C1006
← ←
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
77
CS-E15DTEW CU-E15DBE / CS-E18DTEW CU-E18DBE / CS-E21DTES CU-E21DBE
