13
6. Refrigeration Cycle Diagram
Type of pipe CZ-3F Type
Liquid side pipe Ø 6.35 mm (1/4“)
Gas side pipe Ø 9.52 mm (3/8”)
INDOOR
A
INDOOR B
Silence
r
3-wa
y
valve
3-wa
y
valve
3-wa
y
valve
Silence
r
Expansion
valve A
Expansion
valve B
Capillary
tube
Silence
r
Dr
y
e
r
Capillar
y
tube
4-way
Valve
Heat Exchanger
(Condenser)
Compresso
r
Heat Exchanger
(Evaporator)
Heat Exchanger
(Evaporator)
OUTDOOR
= senso
r
