Panasonic CS-E9GKEW - Outdoor Unit Specifications

6
2.2 Outdoor Unit
Model Name CU-2E15GBE
Indoor Unit Combination 2.2kW + 2.2kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
Capacity kW 4.5 (1.50 – 5.0)
Running Current A 5.75
Power Input kW 1.230 (250 -1350)
Electrical
Data
EER W/W 3.66
Sound Pressure Level dB 47
Cooling Operation
Noise
Sound Power Level dB 62
Capacity kW 5.4 (1.1 – 7.0)
Running Current A 5.20
Power Input kW 1.170 (210 – 1670)
Electrical
Data
COP W/W 4.62
Sound Pressure Level dB 49
Heating Operation
Noise
Sound Power Level dB(A) 64
Maximum Current A 12.0
Starting Current A 5.75
Circuit Breaker Capacity A 15
Dimension Height mm 540
Width mm 780 (+70)
Depth mm 289
Net Weight kg 38
Connection Cable 3 + 1 (Earth) ø1.5 mm
2
Pipe Length Range (1 room) m 3 – 20
Maximum Pipe Length (Total Room) m 30
Refrigerant Pipe Diameter Liquid Side mm 6.35
Gas Side mm 9.52
Compressor Type Scroll Type
Motor Type DC Brushless (4-poles)
Rated Output 1200
Air Circulation Type Propeller Fan
Motor Type DC Brushless (8-poles)
Rated Output 40
Fan Speed Low RPM 690
High RPM 860
Heat Exchanger Type Plate fin configuration forced draft type
Tube Material Copper
Fin Material Aluminum
Row/Stage 2/20
FPI 19
Air Volume High
Cooling
(Heating)
33.3 (28.5)
Refrigerant Control Device Expansion Valve
Refrigerant Oil POE (RB-68A)
Refrigerant (R410A) g 1450
Indoor unit combination Capacity Power Input (kW)
Outdoor Unit
Operation Class (kW)
Operation
Mode
Rating Min - Max Rating Min - Max
Current (A)
Cooling 2.20 1.1 – 2.9 0.52 0.22 – 0.75 2.45 2.2
Heating 3.20 0.7 – 4.8 0.85 0.17 – 1.41 3.75
Cooling 2.80 1.1 – 3.5 0.75 0.22 – 1.00 3.50 2.8
Heating 4.00 0.7 – 5.5 1.15 0.17 – 1.70 5.10
Cooling 3.20 1.1 – 4.0 0.92 0.22 – 1.22 4.30
One-room
Operation
3.2
Heating 4.50 0.7 – 6.2 1.25 0.17 – 1.81 5.55
Cooling 4.50 1.5 – 5.0 1.23 0.25 – 1.35 5.75 2.2 + 2.2
Heating 5.40 1.1 – 7.0 1.17 0.21 – 1.67 5.20
Cooling 4.50 1.5 – 5.2 1.23 0.25 – 1.52 5.75 2.2 + 2.8
Heating 5.40 1.1 – 7.0 1.17 0.21 – 1.67 5.20
Cooling 4.50 1.5 – 5.2 1.25 0.25 – 1.53 5.80
CU-2E15GBE
Two-room
Operation
2.2 + 3.2
Heating 5.40 1.1 – 7.0 1.23 0.21 – 1.72 5.45
