77
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
• “○” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
SFYF0704 - 00
REF. NO. PART NAME & DESCRIPTION QTY. CU-2E15GBE REMARKS
1 CHASSY ASSY 1 CWD50K2058
2 FAN MOTOR BRACKET 1 CWD541089
3 FAN MOTOR,AC 50W SINGLE 1 CWA981072 ○
4 PROPELLER FAN 1 CWH03K1013
5 NUT - PROPELLER FAN 1 CWH561034J
6 COMPRESSOR 1 5CS102XFC ○
7 ANTI - VIBRATION BUSHING 3 CWH501022
8 NUT - COMPRESSOR 3 CWH56000J
9 SOUND PROOF MATERIAL 1 CWG302138
10 SOUND PROOF MATERIAL 1 CWG302139
11 SOUND PROOF MATERIAL 1 CWG302404
12 SOUND PROOF MATERIAL 1 CWG302405
13 CONDENSER COMPLETE 1 CWB32C1816
14 TUBE ASS'Y (CAPPILLARY TUBE) 1 CWT01C4066
15 RECEIVER 2 CWB14013
16 TUBE ASS'Y (CAP.TUBE,MUFLER,EXP VALVE) 1 CWT01C2499
17 TUBE ASS'Y (CAP.TUBE,MUFLER,EXP VALVE) 1 CWT01C2500
18 DISCHARGE MUFFLER 2 CWB121002
19 EXPANSION VALVE 2 CWB051008J
20 4-WAYS VALVE 1 CWB001027J ○
21 STRAINER 1 CWB111004 ○
22 DRYER 1 CWB101016J ○
23 UNION NUT (1/4") 2 CWT251030
24 UNION NUT (3/8") 2 CWT251031
25 V-COIL COMPLETE 2 CWA43C2086J ○
26 V-COIL COMPLETE 1 CWA43C2212 ○
27 SOUND-PROOF BOARD 1 CWH151032
28 HOLDER-SENSOR 1 CWMH320001
29 SENSOR-COMPLETE 1 CWA50C2088 ○
30 HOLDER-SENSOR 3 CWH32138
31 SENSOR-COMPLETE 1 CWA50C2089 ○
32 SENSOR-COMPLETE 1 CWA50C2090 ○
33 HOLDER-SENSOR 2 CWH32074
34 SENSOR-COMPLETE 1 CWA50C2097 ○
35 NORMAL-MODE LINE CHOKE COILS 1 G0A193M00001
36 ELECTRONIC CONTROLLER 1 CWA73C2631R
37 TERMINAL BOARD ASSY 1 CWA28K1162 ○
38 TERMINAL BOARD ASSY 2 CWA28K1045J ○
39 FUSE 1 XBA2C50TR0
40 CONTROL BOARD COVER 1 CWH131116 ○
41 TERMINAL COVER 1 CWH171001
42 RUBBER GASKET 1 CWH7070603
43 3-WAY VALVE (1/4") 2 CWB011418 ○
44 3-WAY VALVE (3/8") 2 CWB011081J ○
45 HOLDER COUPLING 1 CWH351018
46 NUT - TERMINAL COVER 2 CWH7080300J
47 CABINET TOP PLATE 1 CWE031014A
48 CABINET FRONT PLATE CO. 1 CWE06C1136
49 CABINET SIDE PLATE COMP 1 CWE04C1085
50 CABINET SIDE PLATE 1 CWE041074A
51 CONTROL BOARD COVER COMPLETE 1 CWH13C1073
52 HANDLE 1 CWE161010
53 OPERATING INSTRUCTION 1 CWF565585
54 OPERATING INSTRUCTION 1 CWF565586
55 OPERATING INSTRUCTION 1 CWF565587
56 OPERATING INSTRUCTION 1 CWF565627
57 INSTALLATION INSTRUCTION 1 CWF613168
58 INSTALLATION INSTRUCTION 1 CWF613169
59 INSTALLATION INSTRUCTION 1 CWF613170
60 INSTALLATION INSTRUCTION 1 CWF613171
61 INSTALLATION INSTRUCTION 1 CWF612980
62 INSTALLATION INSTRUCTION 1 CWF612981
63 INSTALLATION INSTRUCTION 1 CWF612982
64 INSTALLATION INSTRUCTION 1 CWF613173
65 INSTALLATION INSTRUCTION 1 CWF613174
66 INSTALLATION INSTRUCTION 1 CWF613175
67 INSTALLATION INSTRUCTION 1 CWF613176
68 INSTALLATION INSTRUCTION 1 CWF613179
69 INSTALLATION INSTRUCTION 1 CWF613180
70 INSTALLATION INSTRUCTION 1 CWF613181
