18.3 Piping Length Correction Factor
The characteristic of the unit has to be corrected in accordance with the piping length.
18.3.1 CS/CU-RE18QKE CS/CU-RE24QKE
Cooling Capacity
Correction Factor
Cooling Capacity
Correction Factor
0.95
0.97
0.99
1.01
1.03
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 3
2
0.95
0.96
0.97
0.98
0.99
1.00
1.01
Pipe Length (m)
Heating Capacity
Correction Factor
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 3
2
Pipe Length (m)
Note: The graphs show the factor after added right amount of additional refrigerant.
