Panasonic CS-S18JKQ Service Manual

5
2. Specification
Indoor CS-S18JKQ CS-S24JKQ
Model
Outdoor CU-S18JKQ CU-S24JKQ
Performance Test Condition JIS JIS
Phase, Hz Single, 60Hz Single, 60Hz
Power Supply
V 220 230 220 230
Min. Mid. Max. Min. Mid. Max. Min. Mid. Max. Min. Mid. Max.
kW 0.90 5.20 6.00 0.90 5.20 6.00 0.90 6.00 7.10 0.90 6.00 7.10
BTU/h 3070 17700 20500 3070 17700 20500 3070 20500 24200 3070 20500 24200
Capacity
kJ/h 3240 18720 21600 3240 18720 21600 3240 21600 25560 3240 21600 25560
Running Current A - 6.4 - - 6.3 - - 7.7 - - 7.4 -
Input Power W 240 1.38k 1.68k 240 1.38k 1.68k 310 1.65k 2.00k 310 1.65k 2.00k
W/W 3.75 3.77 3.57 3.75 3.77 3.57 2.90 3.64 3.55 2.90 3.64 3.55
BTU/hW 12.79 12.83 12.20 12.79 12.83 12.20 9.90 12.42 12.10 9.90 12.42 12.10
EER
kJ/hW 13.5 13.6 12.9 13.5 13.6 12.9 10.5 13.1 12.8 10.5 13.1 12.8
Power Factor % - 98 - - 95 - - 97 - - 97 -
dB-A 45 / 36 / 33 45 / 36 / 33 46 / 37 / 34 46 / 37 / 34
Indoor Noise (H / L / QLo)
Power Level
dB
- - - -
dB-A 49 / - 50 / - 49 / - 50 / -
Cooling
Outdoor Noise (H / L)
Power Level
dB
- - - -
Max Current (A) / Max Input Power (W) 8.8 / 1.85k 10 / 2.10k
Starting Current (A) 6.4 7.7
Type Hermetic Motor Hermetic Motor
Motor Type Induction (4-poles) Induction (4-poles)
Compressor
Output Power W 900 900
Type Cross-Flow Fan Cross-Flow Fan
Material ASK30K1 ASK30K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W 69.5 69.5
Output Power W 40 40
QLo rpm 880 - 880 950 - 950
Lo rpm 950 - 950 1020 - 1020
Me rpm 1100 - 1100 1180 - 1180
Hi rpm 1240 - 1240 1340 - 1340
Indoor Fan
Speed
SHi rpm 1400 - 1400 1450 - 1450
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W - -
Output Power W 66 66
Outdoor Fan
Speed Hi rpm 750 - 780 750 - 780
Moisture Removal L/h (Pt/h) 2.9 (6.1) 3.3 (7.0)
QLo
m
3
/min
(ft
3
/min)
12.8 (454) - 12.8 (454) 13.1 (463) - 13.1 (463)
Lo
m
3
/min
(ft
3
/min)
13.9 (490) - 13.9 (490) 14.1 (497) - 14.1 (497)
Me
m
3
/min
(ft
3
/min)
16.1 (567) - 16.1 (567) 16.3 (575) - 16.3 (575)
Hi
m
3
/min
(ft
3
/min)
18.1 (640) - 18.1 (640) 18.5 (650) - 18.5 (650)
Indoor Airflow
SHi
m
3
/min
(ft
3
/min)
20.4 (722) - 20.4 (722) 20.0 (707 ) - 20.0 (707)
Outdoor Airflow Hi
m
3
/min
(ft
3
/min)
38.5 (1360) - 40.3 (1420) 38.5 (1360) - 40.3 (1420)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
RB68A or Freol Alpha68M (400) RB68A or Freol Alpha68M (400)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.13k (39.9) R410A, 1.33k (46.9)
Height(I/D / O/D) mm (inch) 290 (11-7/16) 750 (29-17/32) 290 (11-7/16) 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) 875 (34-15/32) 1070 (42-5/32) 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 235 (9-9/32) 345 (13-19/32) 235 (9-9/32) 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) 46 (101) 12 (26) 48 (106)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.7 (1/2) 6.35 (1/4) / 15.9 (5/8)
Standard length m (ft) 5 (16.4) 5 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 20 (65.6) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 15 (49.2) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 15 (0.2) 15 (0.2)
Piping
Length for Additional Gas m (ft) 10 (32.8) 10 (32.8)
Inner Diameter mm 12 12
Drain Hose
Length mm 550 550
Fin Material Pre Coat Pre Coat
Fin Type Slit Fin Slit Fin
Indoor Heat
Exchanger
Row x Stage x FPI 2 x 15 x 21 2 x 15 x 21
