Model
Indoor CS-TZ20ZKEW CS-TZ25ZKEW
Outdoor CU-TZ20ZKE CU-TZ25ZKE
Compressor
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Synchronous Electric Motor (6 poles) Synchronous Electric Motor (6 poles)
Output Power W 550 550
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG30 ASG30
Motor Type DC (8-poles) DC (8-poles)
Input Power W 43.8 43.8
Output Power W 40 40
Speed
QLo
Cool rpm 550 600
Heat rpm 630 660
Lo
Cool rpm 700 730
Heat rpm 720 770
Me
Cool rpm 840 930
Heat rpm 880 970
Hi
Cool rpm 990 1140
Heat rpm 1030 1180
SHi
Cool rpm 1040 1190
Heat rpm 1080 1230
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi
Cool rpm 800 830
Heat rpm 800 800
Moisture Removal L/h (Pt/h) 1.3 (2.7) 1.5 (3.2)
Indoor Airflow
QLo
Cool m
3
/min (ft
3
/min) 4.97 (175) 5.30 (187)
Heat m
3
/min (ft
3
/min) 5.87 (207) 5.94 (210)
Lo
Cool m
3
/min (ft
3
/min) 6.67 (235) 6.68 (236)
Heat m
3
/min (ft
3
/min) 6.90 (244) 7.10 (251)
Me
Cool m
3
/min (ft
3
/min) 8.26 (292) 8.80 (311)
Heat m
3
/min (ft
3
/min) 8.71 (308) 9.22 (326)
Hi
Cool m
3
/min (ft
3
/min) 9.90 (350) 11.00 (390)
Heat m
3
/min (ft
3
/min) 10.40 (365) 11.50 (405)
SHi
Cool m
3
/min (ft
3
/min) 10.53 (372) 11.56 (408)
Heat m
3
/min (ft
3
/min) 10.98 (388) 11.98 (423)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 29.70 (1050) 30.00 (1060)
Heat m
3
/min (ft
3
/min) 29.70 (1050) 28.90 (1020)
Refrigeration
Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm
3
FW50S (270) FW50S (270)
Refrigerant Type kg (oz) R32, 0.52 (18.4) R32, 0.61 (21.5)
F-Gas
GWP 675 675
CO
2
eq (ton) (Precharged Amount /
Maximum Charged Amount)
0.35 / 0.40 0.41 / 0.46
Dimension
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 290 (11-7/16) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 779 (30-11/16) / 780 (30-23/32) 779 (30-11/16) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 209 (8-1/4) / 289 (11-13/32) 209 (8-1/4) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 8 (18) / 24 (53) 8 (18) / 25 (55)
