14.5.1. Replacement Parts List (Outdoor Unit)
Models:
CU-3E18EBE
REF NO. PART NAME & DESCRIPTION QTY. CU-3E18EBE REMARKS
A1 SWING COMPRESSOR 1 CW1684728
A2 VIBRATION ISOLATOR 3 CW128989J
A3 NUT WITH WASHER 2 CW390214J
A4 TERMINAL COVER 1 CW1262647
A5 RUBBER BUSH, LEAD WIRE 1 CW0401393
A6 RETAINER, OVER-LOAD RELAY 1 CW380620
A8 SOUND INSULATION (SLEEVE) 1 CW1684735
A9 SOUND INSULATION (INNER) 1 CW1684742
A10 SOUND INSULATION (TOP) 1 CW1684759
A13 SOUND INSULATION (MID TOP) 1 CW1684766
B1 CROSS-FIN CONDENSER ASS’Y 1 CW1684773
B1-1 DISTRIBUTOR 1 CW120410J
B3-1 SET PLATE, STOP VALVE (1) 1 CW136410J
B3-2 SET PLATE, STOP VALVE (2) 1 CW130699J
B3-3-1 STOP VALVE ASS’Y (LIQUID LINE) 1 CW130584J
B3-3-2 BODY, MOTORIZED EXP. VALVE 3 CW1684780
B3-3-3 SINGLE UNION JOINT 3 CW060321J
B3-3-4 STRAINER (FOR REF.) 3 CW131823J
B3-3-5 STRAINER (FOR REF.) 1 CW008529J
B3-3-6 PUTTY 3 CW130701J
B3-3-7 FIXTURE, THERMISTOR 3 CW1303896
B3-3-8 PUTTY 1 CW131313J
B3-3-9 SOUNDPROOF PUTTY 1 CW165662J
B3-4-1 STOP VALVE ASS’Y (GAS LINE) 1 CW1684797
B3-4-2 HALF UNION JOINT 3 CW257587J
B3-4-3 FITTING SPRING, THERMISTOR 3 CW380120
B3-5 FIXTURE, UNION JOINT 1 CW131314J
B3-6 FIXTURE, UNION JOINT 1 CW131315J
B3-7 RETAINER, UNION JOINT 1 CW380013J
B3-8 RETAINER 1 CW380080J
B4-1 BODY, FOUR WAY VALVE 1 CW1672857
B4-2-1 MUFFLER 1 CW1170298
B6 FLARE NUT 3 CW119847J
B7 FLARE NUT 3 CW008034J
B9 BLIND CAP, FLARE NUT 3 CW1020920
B10 BLIND CAP, FLARE NUT 3 CW1020937
B12 CAP, STOP VALVE 1 CW045432J
B13 CAP, STOP VALVE 1 CW007993J
B14 SOUNDPROOF PUTTY 1 CW1666085
B15 SOUND ABSORBING PUTTY 1 CW112853J
B18 FITTING SPRING, THERMISTOR 1 CW380120
B19 FIXTURE, THERMISTOR 1 CW1107384
B22 SEALING MATERIAL (HEAT EXCH. TOP) 3 CW1684805
C1 FAN BLADE ASS’Y 1 CW1684812
C2 LOCK NUT, FAN BLADE 1 CW847002J
C3 GUARD NET 1 CW118238J
C4 AIR DISCHARGE GRILLE 1 CW163114J
E1 BODY, SWITCH BOX 1 CW1684829
E3 HEAT SINK ASS’Y 1 CW1684836
E4 SWITCH BOX ASS’Y 1 CW1684843
E4-1 SEALING MATERIAL 1 CW1684850
E5 WIRE HARNESS ASS’Y 1 CW1684867
E6 PRINTED CIRCUIT ASS’Y (CONTROL) 1 CW1684874
E6-1 FUSE 1 CW1684881
E6-2 FUSE 2 CW153875J
E7 PRINTED CIRCUIT ASS’Y (SERVICE) 1 CW1684898
E8 TERMINAL BLOCK ASS’Y 1 CW1684906
E8-1 TERMINAL BLOCK 1 CW1684913
E8-2 TERMINAL BLOCK 3 CW1684920
E11 THERMISTOR ASS’Y (LIQUID) 1 CW130943J
E12 THERMISTOR ASS’Y (GAS) 1 CW1684937
E13 OVER LOAD RELAY 1 CW622423J
E14 REACTOR 1 CW1684944
E15 THERMISTOR ASS’Y 1 CW1684951
E17 COIL ASS’Y, FOUR WAY VALVE 1 CW1684968
E17-1 COIL, FOUR WAY VALVE 1 CW148574J
E18 COIL ASS’Y, MOTORIZED EXP. VALVE 1 CW131335J
E18-1 COIL, MOTORIZED EXP. VALVE 1 CW130523J
E18-2 COIL, MOTORIZED EXP. VALVE 1 CW130524J
135
