REF NO. PART NAME & DESCRIPTION QTY. CU-3E18EBE REMARKS
E18-3 COIL, MOTORIZED EXP. VALVE 1 CW130521J
E19 INSULATOR 1 CW137031J
E20 DC FAN MOTOR ASS’Y 1 CW1684975
E21 SET SCREW 1 CW136116J
E22 GROUNDING TIP (W/WASHER) 2 CW113783J
E23 CUSHION RUBBER, SWITCH BOX 1 CW130707J
E24 LATCH 1 CW0444491
E25 WIRE HARNESS (FOR COMP.) 1 CW1684982
E26 CLAMP, LEAD WIRE 1 CW1364156
F1 BOTTOM FRAME ASS’Y 1 CW165694J
F2 SIDE PLATE ASS’Y (RIGHT) 1 CW1684999
F2-1 SIDE PLATE (RIGHT) 1 CW130728J
F2-2 SOUND INSULATION (RIGHT) 1 CW1685000
F2-3 SEALING MATERIAL (RIGHT SIDE) 1 CW1685017
F3 FRONT PLATE ASS’Y 1 CW139741J
F4 FRONT PLATE ASS,Y 1 CW1685024
F5 PARTITION PLATE 1 CW1685031
F6 MOTOR BASE 1 CW163127J
F7 COVER, STOP VALVE 1 CW165665J
F7-1 SOUND INSULATION (STOP VALVE) 1 CW1685048
F7-2 SEALING MATERIAL 1 CW1685055
F9 HANDLE 1 CW1379754
F12 TAPPING SCREW 4 CW140380J
F14 HEX. HEAD TAPPING SCREW 19 CW109224J
F15 TRUSS HEAD TAPPING SCREW 17 CW008203J
F17 TOP PLATE 1 CW118234J
F18 SEALED BOARD ASS’Y 1 CW1685062
F18-1 SEAL PLATE 1 CW137974J
F18-2 SEALING MATERIAL 2 CW1437410
F21 HOLE PROTECTION RUBBER 1 CW144136J
K1 NAME PLATE 1 CW1685079
K2 DRAIN JOINT 1 CW0589565
K3 SCREW KIT 1 CW136424J
K4 COLLECTIVE INDICATIONS LABEL 1 CW1685086
K5 OPERATION NAME PLATE 1 CW1387793
K6 CAUTION LABEL 1 CWF734916
K7 INDICATION LABEL (TERMINAL) 1 CW1685093
K8 BADGE 1 CW1685101
K9 NAME PLATE 1 CW1685118
K11 OPERATION MANUAL ASS’Y 1 CWF565237
K12 OPERATION MANUAL ASS’Y 1 CWF565238
K13 INSTALLATION MANUAL (OUTDOOR UNIT) 1 CWF612778
K14 INSTALLATION MANUAL (OUTDOOR UNIT) 1 CWF612779
K15 INSTALLATION MANUAL (OUTDOOR UNIT) 1 CWF612780
K16 INSTALLATION MANUAL (CELLING FLOOR TYPE) 1 CWF612822
K17 INSTALLATION MANUAL (CELLING FLOOR TYPE) 1 CWF612823
K18 INSTALLATION MANUAL (CELLING FLOOR TYPE) 1 CWF612824
K19 INSTALLATION MANUAL (MINI-CASSETTE) 1 CWF612825
K20 INSTALLATION MANUAL (MINI-CASSETTE) 1 CWF612826
K21 INSTALLATION MANUAL (MINI-CASSETTE) 1 CWF612827
K22 INSTALLATION MANUAL (WALL TYPE) 1 CWF612819
K23 INSTALLATION MANUAL (WALL TYPE) 1 CWF612820
K24 INSTALLATION MANUAL (WALL TYPE) 1 CWF612821
K25 INSTALLATION MANUAL (WALL TYPE) 1 CWF612816
K26 INSTALLATION MANUAL (WALL TYPE) 1 CWF612817
K27 INSTALLATION MANUAL (WALL TYPE) 1 CWF612818
(Note)
• Parts other the operation manual and installation manual are parts for RoHS.
• “
” marked parts are recommended to be kept in stock.
136 [ACD] Printed in Japan
