Panasonic CU-3TZ52TBE - Page 12

12
 Multi Split Combination Possibility:
o A single outdoor unit enables air conditioning of up to three separate rooms for CU-3TZ52TBE.
CONNECTABLE INDOOR UNIT CU-3TZ52TBE
ROOM A B C
Wall
1.6kW CS-MTZ16TKE ● ● ●
2.0kW
CS-TE20TKEW
CS-TZ20TKEW
CS-TZ20TKEW-1
● ● ●
2.5kW
CS-TE25TKEW
CS-TZ25TKEW
CS-TZ25TKEW-1
● ● ●
3.5kW
CS-TE35TKEW
CS-TZ35TKEW
CS-TZ35TKEW-1
● ● -
4.2kW
CS-TE42TKEW
CS-TZ42TKEW
CS-TZ42TKEW-1
● ● -
5.0kW
CS-TE50TKEW
CS-TZ50TKEW
●
- -
Capacity range of connectable units From 4.5kW to 9.5kW
Pipe length
1 room maximum pipe length (m) 25
Allowable elevation (m) 15
Total allowable pipe length (m) 50
Total pipe length for maximum
chargeless length (m)
30
Additional gas amount over
chargeless length (m)
20
Note: “•” : Available
Remarks for CU-3TZ52TBE
1. At least two indoor units must be connected.
2. The total nominal cooling capacity of indoor unit that will be connected to outdoor unit must be within connectable capacity range of indoor
unit. (as shown in the table above)
Example: The indoor units’ combination below is possible to connect to CU-3TZ52TBE. (Total nominal capacity of indoor units is between
4.5kW to 9.5kW)
1) Two CS-TZ25TKEW only. (Total nominal cooling capacity is 5.0kW)
