19. Service Data
Service Data provided are based on the air conditioner running under rated frequency during forced cooling / forced
heating mode.
19.1 Operation Characteristics (CU-3TZ52TBE)
19.1.1 One Indoor Unit Operation
 Cooling Characteristic
[Condition] Room temperature: 27°C (DBT), 19°C (WBT)
Operation condition: High fan speed
Piping length: 5.0 m
Voltage: 230V, 50Hz
A) Indoor unit capacity: Cooling (2.0), CS-TZ20TKEW
Indoor Discharge Air
Temperature (°C)
Outdoor Air Temperature (°C)
11.200
11.700
12.200
12.700
13.200
13.700
14.200
14.700
15.200
15.700
16.200
-10-6 -2 2 6 10141822263034384246
Outdoor Air Temperature (°C)
Current
(A)
2.700
3.360
4.020
4.680
5.340
6.000
-10-6 -2 2 6 10141822263034384246
Gas Side Piping
Pressure (MPa)
Outdoor Air Temperature (°C)
0.700
0.730
0.760
0.790
0.820
0.850
0.880
0.910
0.940
0.970
1.000
-10-6 -2 2 6 10141822263034384246
