Panasonic CU-3TZ52TBE - Page 27

27
Applicable to
Liquid and Gas side of
CS-MTZ16***,
CS-TZ20***,
CS-TZ25***,
CS-TZ35***,
CS-TZ42***,
CS-TZ50***,
CS-TE20***,
CS-TE25***,
CS-TE35***,
CS-TE42***,
CS-TE50***
Female side
Screw
Screw
Control Board Cover (resin)
Flare Nut
Torque Wrench for Flare Nut
(Connection Pipe)
(Connection Pipe)
Torque Wrench for Flare Nut
Liquid
side
Gas side
Flare Nut
Male side
