 Heating Characteristic
[Condition] Room temperature: 20°C (DBT), 12°C (WBT)
Operation condition: High fan speed
Piping length: 5.0 m
Voltage: 230V, 50Hz
C) Indoor unit capacity: Heating (4.2), CS-Z42TKEW
Outdoor Air Temperature (°C)
Indoor Discharge Ai
r
Temperature (°C)
-16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12
30.000
31.800
33.600
35.400
37.200
39.000
40.800
42.600
44.400
46.200
48.000
Outdoor Air Temperature (°C)
Current
(A)
-16-14-12-10-8-6-4-2024681012
6.000
6.340
6.680
7.020
7.360
7.700
Outdoor Air Temperature (°C)
Gas Side Piping
Pressure (MPa)
-16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12
2.300
2.420
2.540
2.660
2.780
2.900
3.020
3.140
3.260
3.380
3.500
