Panasonic CU-3Z52TBE - Multi-Indoor Unit Operation Characteristics

259
19.1.2 Two Indoor Unit Operation
 Cooling Characteristic
[Condition] Room temperature: 27°C (DBT), 19°C (WBT)
Operation condition: High fan speed
Piping length: 5.0 m
Voltage: 230V, 50Hz
A) Indoor unit capacity: Cooling (2.0 + 2.5), CS-Z20TKEW + CS-Z25TKEW
Outdoor Air Temperature (°C)
Indoor Discharge Air
Temperature (°C)
Z20TKEW Z25TKEW
-10-6 -2 2 6 10141822 2630 3438 4246
12.000
12.600
13.200
13.800
14.400
15.000
15.600
16.200
16.800
17.400
18.000
Outdoor Air Temperature (°C)
Current
(A)
-10-6-2 2 6 10141822263034384246
2.900
3.660
4.420
5.180
5.940
6.700
Outdoor Air Temperature (°C)
Gas Side Piping
Pressure (MPa)
-10-6-2 2 6 10141822263034384246
0.800
0.840
0.880
0.920
0.960
1.000
1.040
1.080
1.120
1.160
1.200
