 Heating Characteristic
[Condition] Room temperature: 20°C (DBT), 12°C (WBT)
Operation condition: High fan speed
Piping length: 5.0 m
Voltage: 230V, 50Hz
A) Indoor unit capacity: Heating (2.0 + 2.5), CS-Z20TKEW + CS-Z25TKEW
Outdoor Air Temperature (°C)
Indoor Discharge Air
Temperature (°C)
Z20TKEW Z25TKEW
27.000
28.600
30.200
31.800
33.400
35.000
36.600
38.200
39.800
41.400
43.000
-16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12
Outdoor Air Temperature (°C)
Current
(A)
7.700
8.160
8.620
9.080
9.540
10.000
-16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12
Outdoor Air Temperature (°C)
Gas Side Piping
Pressure (MPa)
2.200
2.280
2.360
2.440
2.520
2.600
2.680
2.760
2.840
2.920
3.000
-16-14-12-10-8-6-4-2024681012
