19.3.2 Two Indoor Unit Operation
 Cooling Characteristic
[Condition] Room temperature: 27°C (DBT), 19°C (WBT)
Operation condition: High fan speed
Piping length: 5.0 m
Voltage: 230V, 50Hz
A) Indoor unit capacity: Cooling (2.5 + 3.5), CS-Z25TKEW + CS-Z35TKEW
Outdoor Air Temperature (°C)
Indoor Discharge Air
Temperature (°C)
Z25TKEW Z35TKEW
-10-6 -2 2 6 10141822 2630 3438 4246
12.000
12.500
13.000
13.500
14.000
14.500
15.000
15.500
16.000
16.500
17.000
Outdoor Air Temperature (°C)
Current
(A)
-10-6-2 2 6 10141822263034384246
3.100
3.900
4.700
5.500
6.300
7.100
Outdoor Air Temperature (°C)
Gas Side Piping
Pressure (MPa)
-10-6-2 2 6 10141822263034384246
0.900
0.930
0.960
0.990
1.020
1.050
1.080
1.110
1.140
1.170
1.200
