Panasonic CU-4E27PBE - Heat Mode Outdoor Air Temperature Characteristic

129
21.2 Heat Mode Outdoor Air Temperature Characteristic
Condition
- Indoor room temperature: 20°C Dry Bulb/ -°C Wet Bulb
- Unit setting: Standard piping length, forced heating at 30°C, Hi fan
- Compressor frequency: Rated for Heating operation
- Piping length: 5m
- Voltage: 230V
21.2.1 CS-TZ60TKEW CU-TZ60TKE
Indoor Discharge
Air Temperature (°C)
Outdoor Air Temperature (°C)
High Pressure (MPa)
Outdoor Air Temperature (°C)
Current (A)
Outdoor Air Temperature (°C)
6.00
7.00
8.00
9.00
10.00
11.00
12.00
13.00
14.00
-16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12 14 16 18 20 22 24 26
25.00
30.00
35.00
40.00
45.00
50.00
55.00
60.00
-16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12 14 16 18 20 22 24 26
1.50
2.00
2.50
3.00
3.50
4.00
4.50
5.00
-16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12 14 16 18 20 22 24 26
