Panasonic CU-4E27PBE - Outdoor Unit

23
6.2 Outdoor Unit
32045
695
386
7570.5
(25)
7.7
34.7
(131)
613 131
875 72
360.5
82 35
<Top View>
<Front View><Side View>
<Side View>
Anchor Bolt Pitch
360.5 × 613
Space necessary for
installation
100mm
100mm
100mm
Unit : mm
3-way valve at Gas side
(Low Pressure)
2-way valve at Liquid side
(High Pressure)
