133
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-TZ60TKEW CS-TZ71TKEW REMARK
1 CHASSIS COMPLETE 1 ACXD50C00280 ←
2 FAN MOTOR 1 L6CBYYYL0193 ARW7677AC
O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1136 ←
4 BEARING ASSY 1 CWH64K1010 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 PARTICULAR PIECE 1 CWD933067B ←
7 EVAPORATOR 1 ACXB30C02760 ACXB30C02870
8 FLARE NUT (LIQUID) 1 CWT251030 ←
9 FLARE NUT (GAS) 1 CWT251032 CWT251033
10 CONTROL BOARD CASING 1 ACXH10-00720 ←
11 PARTICULAR PIECE - TERMINAL 1 CWD933137 ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2357 ←
O
13 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C23090 ACXA73C23100
O
14 ELECTRONIC CONTROLLER - INDICATOR 1 ACXA73-07330 ←
O
15 INDICATOR HOLDER 1 ACXD93-01960 ←
16 SENSOR COMPLETE 1 CWA50C3226 CWA50C2664
O
17 CONTROL BOARD TOP COVER 1 ACXH13-00430 ←
18 DISCHARGE GRILLE COMPLETE 1 ACXE20C00490 ←
19 BACK COVER CHASSIS 1 CWD933463B ←
20 FULCRUM 2 ACXH62-00080 ←
21 VERTICAL VANE 11 ACXE24-00400 ←
22 CONNECTING BAR 1 ACXE26-00190 ←
23 CONNECTING BAR 1 ACXE26-00200 ←
24 AIR SWING MOTOR 1 ACXA98K00030 ←
25 AIR SWING MOTOR 1 CWA981299 ←
O
26 AIR SWING MOTOR 1 CWA981304 ←
27 CAP - DRAIN TRAY 1 CWH521259 ←
28 HORIZONTAL VANE COMPLETE 1 ACXE24C00550 ←
29 HORIZONTAL VANE COMPLETE 1 ACXE24C00540 ←
30 CONTROL BOARD COVER - COMPLETE 1 ACXH13C00150 ←
31 REMOTE CONTROL COMPLETE 1 ACXA75C00430 ←
O
32 FRONT GRILLE COMPLETE 1 ACXE10C02690 ACXE10C02700
O
33 INTAKE GRILLE COMPLETE 1 ACXE22K01090 ←
34 GRILLE DOOR COMPLETE 1 ACXE14C00050 ←
35 AIR FILTER 2 ACXD00-00250 ←
O
36 SCREW - FRONT GRILLE 4 XTT4+16CFJ ←
37 CAP - FRONT GRILLE 3 ACXH52-00100 ←
38 DRAIN HOSE 1 CWH851173 ←
39 INSTALLATION PLATE 1 CWH361098 ←
40 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
41 AIR PURIFYING FILTER 1 CWD00C1293 ←
42 OPERATING INSTRUCTION 1 ACXF55-04100 ←
43 OPERATING INSTRUCTION 1 ACXF55-04110 ←
44 INSTALLATION INSTRUCTION 1 ACXF60-05670 ←
45 INSTALLATION INSTRUCTION 1 ACXF60-05680 ←
46 INSTALLATION INSTRUCTION 1 ACXF60-05690 ←
47 INSTALLATION INSTRUCTION 1 ACXF60-05700 ←
48 INSTALLATION INSTRUCTION 1 ACXF60-05710 ←
49 INSTALLATION INSTRUCTION 1 ACXF60-05720 ←
50 INSTALLATION INSTRUCTION 1 ACXF60-05730 ←
