SAFETY REF. NO. DESCRIPTION & NAME QTY. CU-4E27QBR CU-5E34QBR REMARK
1 BASE PAN ASS'Y 1 CWD52K1345A ←
2 SOUND-PROOF BOARD 1 CWH151367 ←
3 FAN MOTOR BRACKET 1 CWD54K1081 ←
4 SCREW-BRACKET FAN MOTOR 3 CWH551217 ←
5 CONDENSER COMPLETE 1 CWB32C4000 ←
6 FAN MOTOR 1 L6CBYYYL0098 ← O
7 SCREW-FAN MOTOR MOUNT 4 CWH551323 ←
8 PROPELLER FAN ASSY 1 CWH03K1075 ←
9 NUT 1 CWH561092 ←
10 COMPRESSOR 1 5KD240XAL21 ← O
12 BUSHING - COMPRESSOR MOUNT 3 CWH50055 ←
13 NUT-COMPRESSOR MOUNT 3 CWH561049 ←
14 CRANKCASE HEATER 1 CWA341093 ←
16 ACCUMLATOR 1 CWB131064 ←
17 3-WAYS VALVE (GAS) 1 CWB011769 ←
18 3-WAY VALVE (LIQUID) 1 CWB011770 ←
19 HOLDER COUPLING 1 CWH351262 ←
20 STRAINER 1 CWB11061 ←
21 STRAINER 4/5 CWB111081 ←
22 EXPANSION VALVE 4/5 CWB051029 ←
23 4-WAYS VALVE 1 CWB001026J ←
24 DISCHARGE MUFFLER 1 CWB121014 ←
25 HEATING PRESSURE SWITCH 1 CWA101013 ←
26 FLARE NUT (1/4) 4/5 CWT251030 ←
27 FLARE NUT (3/8) 4/5 CWT251031 ←
28 SOUND PROOF MATERIAL 1 CWG302804 ←
31 SOUND PROOF MATERIAL 1 CWG302801 ←
32
SENSOR-COMPLETE (DISCHARGE TEMP
SENSOR CN-DIS)
1 CWA50C3091 ← O
33 V-COIL CO. (4 WAY VALVE CN-HOT) 1 CWA43C2586 ← O
34 V-COIL CO. (EXPAND VALVE-WHITE CN-EV1) 1 CWA43C2587 ← O
35
V-COIL CO. (EXPAND VALVE-YELLOW CN-
EV2)
1 CWA43C2588 ← O
36 V-COIL CO. (EXPAND VALVE-BLUE CN-EV3) 1 CWA43C2589 ← O
37 V-COIL CO. (EXPAND VALVE-RED CN-EV4) 1 CWA43C2590 ← O
38
SENSOR-COMPLETE (DEFROST TEMP
SENSOR CN-TH2)
1 CWA50C3087 ← O
39
SENSOR-COMPLETE (OUTDOOR TEMP
SENSOR CN-TH1)
1 CWA50C3088 O
40 SENSOR-COMPLETE (CN-TH4) 1 CWA50C3131 CWA50C3089 O
41 SENSOR-COMPLETE (CN-TH3) 1 CWA50C3132 CWA50C3090 O
42 V-COIL CO. (EXPAND VALVE-BLACK CN-EV5) 1 - CWA43C2591 O
43 ELECTRONIC CONTROLLER-MAIN 1 CWA73C8448R CWA73C8449R O
44 ELECTRONIC CONTROLLER (NOISE FILTER) 1 CWA73C7265 ← O
45 ELECTRONIC CONTROLLER (DISPLAY) 1 CWA747223 ← O
47 REACTOR 1 G0C602J00009 ←
48 TERMINAL BOARD ASS'Y (L,N) 1 CWA28K1195 ←
49 TERMINAL BOARD ASS'Y (1, 2, 3) 4/5 CWA28K1196 ←
50 CONTROL BOARD COVER (TOP PCB) 1 CWH131613 ←
51 CABINET REAR PLATE-COMPLETE 1 CWE02C1078 ←
52 CABINET TOP PLATE 1 CWE03C1150 ←
