9
2.3 CU-5E34QBR
Item Unit OUTDOOR UNIT
Indoor Unit Combination 2.0kW + 2.0kW + 2.0kW + 2.0kW + 2.0kW
Phase, Hz Single, 50
Power Source
V 230 240
Min. Mid. Max.
kW 2.90 10.00 11.50
Capacity
BTU/h 9890 34100 39200
Running Current A 13.6 13.2
Power Input kW 0.55 2.86 3.86
EER W/W 5.27 3.50 2.98
Electrical
Data
Power Factor % 91 90
Sound Pressure Level dB-A (H/L) 53/ - 53/ -
Cooling Operation
Noise
Sound Power Level dB (H/L) 69 / - 69 / -
kW 3.40 12.00 14.50
Capacity
BTU/h 11600 40900 49400
Running Current A 13.6 13.2
Power Input kW 0.53 2.96 4.24
COP W/W 6.42 4.05 3.42
Electrical
Data
Power Factor % 95 93
Sound Pressure Level dB-A (H/L) 54 / - 54 / -
Heating Operation
Noise
Sound Power Level dB (H/L) 70 / - 70 / -
Maximum Current A 21.3
Maximum Input Power kW 4.84
Starting Current A 13.6
Height mm 999
Width mm 940
Dimension
Depth mm 340
Net Weight kg 81
Connection Cable 4 x 1.5 mm
2
Pipe Length Range (1 room) m 3 ~ 25
Maximum Pipe Length (Total Room) m 80
Standard Length m 5
Height Different m 15
Additional Gas Amount g/m 20
Pipe Length for Additional Gas m 45
Liquid Side mm (inch) 6.35 (1/4)
Refrigerant Pipe Diameter
Gas Side mm (inch) 9.52 (3/8) / 12.7 (1/2) [MRE24]
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Compressor
Rated Output kW 1.70
Type Propeller Fan
Motor Type DC Motor (8-poles)
Fan Motor
Rated Output W 90
Fan Speed High (Cooling / Heating) RPM 650 / 740
