7
2.2 CU-4E27QBR
Item Unit OUTDOOR UNIT
Indoor Unit Combination 2.0kW + 2.0kW + 2.0kW + 2.0kW
Phase, Hz Single, 50
Power Source
V 230 240
Min. Mid. Max.
kW 3.00 8.00 9.20
Capacity
BTU/h 10200 27300 31400
Running Current A 9.8 9.4
Power Input kW 0.53 2.15 2.87
EER W/W 5.66 3.72 3.21
Electrical
Data
Power Factor % 95 95
Sound Pressure Level dB-A (H/L) 61 / - 61 / -
Cooling Operation
Noise
Sound Power Level dB (H/L) 67 / - 67 / -
kW 4.20 9.40 10.60
Capacity
BTU/h 14300 32100 36100
Running Current A 10.2 9.8
Power Input kW 0.70 2.18 3.06
COP W/W 6.00 4.31 3.46
Electrical
Data
Power Factor % 93 93
Sound Pressure Level dB-A (H/L) 52 / - 52 / -
Heating Operation
Noise
Sound Power Level dB (H/L) 68 / - 68 / -
Maximum Current A 19.0
Maximum Input Power kW 4.33
Starting Current A 10.2
Height mm 999
Width mm 940
Dimension
Depth mm 340
Net Weight kg 80
Connection Cable 4 x 1.5 mm
2
Pipe Length Range (1 room) m 3 ~ 25
Maximum Pipe Length (Total Room) m 70
Standard Length m 5
Height Different m 15
Additional Gas Amount g/m 20
Pipe Length for Additional Gas m 45
Liquid Side mm (inch) 6.35 (1/4)
Refrigerant Pipe Diameter
Gas Side mm (inch) 9.52 (3/8), 12.7 (1/2) [MRE24 only]
Type Hermetic Motor / Rotary
Motor Type Brushless Motor (4-poles)
Compressor
Rated Output kW 1.70
Type Propeller Fan
Motor Type DC Motor (8-poles)
Fan Motor
Rated Output W 90
Fan Speed High (Cooling / Heating) RPM 600 / 600
