CS-MA90KE
Heat
Exchanger
Refrigerant Control Device
Refrigeration Oil
Refrigeration (R-22)
Thermostat
Protection Device
Capillary Tube
Air Filter
Capacity Control
Compressor Capacitor
Fan Motor Capacitor
Description
Tube material
Fin material
Fin Type
Row / Stage
FPI
Size (W × H × L)
µF, VAC
µF, VAC
Length
Flow Rate
Inner Diameter
Material
Style
Unit
mm
(c.c)
g (oz)
mm
s/min
mm
Product Specifications
CS-MA90KE
Evaporator
Copper
Aluminium
Slot Fin
2 × 12
18
600 × 252 × 25.4
–
–
–
Electronic Control
–
–
–
–
P.P.
Honeycomb
–
–
(Plate fin configuration, forced draft)
Capillary Tube
• Specifications are subject to change without notice for further improvement.
CU-MA180KE
Condenser
Copper
Aluminium
Corrugated Fin
1 × 18
19
856 × 457.2 × 22
Capillary Tube
SUNISO 4GDID or
ATMOS M60 (350 × 2)
850 × 2 (30.0 × 2)
–
Overload Protector
Cooling ; 1,033, Heating ; 585
Cooling ; 4.8, Heating ; 9.9
Cooling ; 1.2, Heating ; 1.4
–
–
25 µF, 370VAC
(Upper unit) 1.0 µF, 400VAC
(Lower unit) 1.2 µF, 400VAC
