8.2. Outline of installation
Installation works Installation parts Required tools
1. Installation of indoor, outdoor unit
Installation plate
A level gauge
1) Selet the best location........P.28
4 wooden screws
Philips screw driver
2) Indoor unit installation........P.29
4 anchor bolts
Electric drill hole coredrill (Ø70mm)
Side cutter or electrical pliers
2. Piping and drainage of indoor unit
Pipes: Gas side................... 1/2"
Flaring tools set
1) Prepare of piping........P.30 Gas side....................3/8" Specified torque wrenches
2) Connection of piping........P.31 Liquid side............. ...1/4" 18N.m.......Liquid side piping
For the right piping........P.31
Insulated drain hose 42N.m.......Gas side piping
For the left piping........P.32
Insulation materials 55N.m.......Gas side piping
Spanner.......Half union
3. In case of Embedded Piping
Pipes: Gas side................... 1/2"
Flaring tools set
For the embedded piping........P.34 Gas side....................3/8" Specified torque wrenches
Liquid side............. ...1/4" 18N.m.......Liquid side piping
Insulated drain hose 42N.m.......Gas side piping
Insulation materials 55N.m.......Gas side piping
Spanner.......Half union
4. Connecting piping and cable to the
outdoor unit
Additional drain hose
Specified torque wrenches
(Outer diameter......1.55mm) 18N.m.......Liquid side
1) Connecting the piping to the outdoor
unit........P.35
Connecting cable 42N.m.......Gas side
(5-core wire/1.5mm
2
) 55N.m.......Gas side
2) Connecting the cable........P.35 Locally approved cable
5. Air purging of the piping and indoor unit
Installation materials provided
Hexagonal wrench
1) Air purging........P.36
Tape provided
Gas leak detector
6.
Checking the drainage and connecting
the cable to indoor unit
Connecting cable
A glass of water
1) Checking the drainage........P.37 (5-core wire/1.5mm
2
)
Phillips screw driver
2) Connecting the inside/ outside
cable........P.38
Locally approved cable
3) Connect the cable to the indoor unit
........P.38
7. Test Running
Circuit breaker or time delay fuse
(consult an electrician)
1) Connect the power supply........P.39
2) Evaluation of the performance
........P.39
Operating instructions
Thermometer
27
CS-SA9CKP CU-SA9CKP5 / CS-SA12CKP CU-SA12CKP5
