Specifications
Reference
Specifications are subject to change without
notice.
∫ General
Dimensions: 430 mm (W)
59 mm (H)
(excluding the projecting parts)
238 mm (D)
(including the projecting parts)
249 mm (D)
Mass: [PWT635] Approx. 3.0 kg
[PWT530] Approx. 2.9 kg
Power supply: AC 220 V to 240 V, 50 Hz
Power consumption: [PWT635] Approx. 29 W
[PWT530] Approx. 27 W
Power consumption in standby mode:
“Quick Start” is activated and “Power Save
for Network Standby” is set to “Off”
Approx. 5 W
“Quick Start” is activated and “Power Save
for Network Standby” is set to “On”
Approx. 4 W
“Quick Start” is not activated and
“RF OUT ( Aerial Signal )” is set to “Off”
Approx. 0.2 W
Operating temperature: 5 oC to 40 oC
Operating humidity range: 10 % to 80 % RH
(no condensation)
∫ TV system
Tuner System: DVB-T
Country: Australia
Channel Coverage: VHF 6~12
UHF 27~69
∫ Recording system
Video: MPEG-2,
MPEG-4 AVC/H.264
Audio:
Dolby Digital
(DR mode: Max 5.1ch (DVB-T))
HE-AAC (DR mode: 2ch (DVB-T))
MPEG (DR mode: 2ch)
∫ Audio
Analog audio L/R out (pin jack): 1 pc.
Output level:
Full scale 2.0 Vrms at 1 kHz (< 1 k≠)
Digital audio out (optical): 1 pc.
PCM, Dolby Digital, DTS, MPEG
∫ HDMI terminal
HDMI output (19 pin type A): 1 pc.
PCM, Dolby Digital, DTS, MPEG,
Dolby Digital Plus, Dolby TrueHD,
DTS-HD Master Audio,
DTS-HD High Resolution Audio
• This unit supports “HDAVI Control 5”
function.
∫ Internal HDD capacity
[PWT635] 1TB
[PWT530] 500 GB
∫ Other terminals
USB Port (Type A): 2 pcs.
SD Card Slot: 1 pc.
LAN (Ethernet) Port: 1 pc.
10BASE-T/100BASE-TX
∫ Wireless LAN
Standard compliance: IEEE802.11b/g/n
Frequency range: 2.4 GHz band
Security
§
:
WPA™/WPA2™
(Encryption type: TKIP/AES,
Authentication type: PSK)
WEP (64 bit/128 bit)
§
This unit supports WPA and WPA2
encryption.
