Panasonic DMC-FT1EB - S3. Block Diagram; S3.1. Overall Block Diagram

S-3
S3. Block Diagram
S3.1. Overall Block Diagram
CCD
IC3001
FOCUS
IRIS
/512Mbit
IC6002
SDRAM/512Mbit
SD
CARD
IC5001
AUDIO INTERFACE
IC9601
MONAURAL 16bit CODEC
MICROPHONE
(SWITCHING REGULATOR)
REAR OPERATION UNIT
IC9101
IC9101
OIS DRIVE &
IC6001
VENUS 4
STROBE
IC1001
POWER
SHUTTER
IC9101
ZOOM
1/2.33" 12.1 MEGA PIX
TERMINAL
COLOUR LCD
2.7" PANEL
SPEAKER
MICROPHONE ANT
HDMI
JK2004
VIDEO AUDIO L/R
USB/DC
IC7101
GYRO
SENSOR X/Y
DMC-FT1, TS1 OVERALL BLOCK DIAGRAM
MONAURAL MIC AMP
MONAURAL LINE AMP
SPEAKER AMP
230K PIX
(Type of LCD Driver inclusion)
(4.9mm - 22.8mm
OISUNIT
PREPROCESS
CDS,AGC,
A/D,TG,
CCD DRIVER
MOTOR DRIVE,
PRE PROCESS
SYSTEM
DRIVER
CAMERA PROCESS
J-PEG COMP/EX PANDS
MEDIA I/F
USB I/F
MAIN MICRO PROCESSOR
OIS CONTROL
LENS DRIVE
LCD DRIVE
FLASH ROM
HDMI CONTROLER
SYSTEM DRIVER
(VIDEO 6dB AMP)
AV/USB/DC
JK2001
PANEL
BATTERY
TOP OPERATION UNIT
