Ref. No. Part No. Part Name & Description Pcs Remarks
RX6724 D1H84704A024 RESISTOR-RESISTOR 1
RX6726-28 D1H84704A024 RESISTOR-RESISTOR 3
RX6731-34 D1H84704A024 RESISTOR-RESISTOR 4
RX6735 D1H82224A024 RESISTOR-RESISTOR 1
RX6736 D1H81034A024 RESISTOR-RESISTOR 1
RX6737 D1H84724A024 RESISTOR-RESISTOR 1
RX6738 D1H83334A024 RESISTOR-RESISTOR 1
RX50001-16 D1H84704A024 RESISTOR-RESISTOR 16
X3401 H0J270500069 CRYSTAL OSCILLATOR 1
05 REP3713A (FRONT(R) P.C.B.)
C7801 ECJ1VF1A105Z 10V 1U 1
D7801 B3ABA0000396 DIODE 1
IR7801 B3RAD0000071 REMOTE SENSOR 1
P7801 K1KA12B00136 CONNECTOR(12P) 1
QR7801 UN2214 TRANSISTOR 1 UNR2214
R7801 ERDS2FJ330 1/4W 33 1
R7802 ERJ3GEYJ221V 1/10W 220 1
R7809 ERJ3RBD272 1/16W 2.7K 1
R7817 ERJ3RBD272 1/16W 2.7K 1
R7818 ERJ3RBD222V 1/16W 2.2K 1
R7819 ERA3YED332 1/16W 3.3K 1
R7825 ERJ3RBD272 1/16W 2.7K 1
R7826 ERJ3RBD222V 1/16W 2.2K 1
R7827 ERA3YED332 1/16W 3.3K 1
S7801 EVQ11G07K SWITCH(OPEN/CLOSE) 1
S7802 EVQ11G07K SWITCH(SKIP-F) 1
S7809 EVQ11G07K SWITCH(CH-DOWN) 1
S7811 EVQ11G07K SWITCH(REC) 1
S7812 EVQ11G07K SWITCH(STOP) 1
S7813 EVQ11G07K SWITCH(SKIP-R) 1
S7819 EVQ11G07K SWITCH(CH-UP) 1
S7820 EVQ11G07K SWITCH(TIME-SLIP) 1
S7821 EVQ11G07K SWITCH(PLAY) 1
