Panasonic DMR-EZ49VEB

30
7.2.2. (VHS) Service Modes
1. Set DRIVE SELECT to VHS.
2. When power is off, press [STOP] and [EJECT] keys simultaneously for 3 seconds to into Service Mode.
3. In service mode, press [STOP] and [EJECT] keys simultaneously to add Service Number.
Service
Mode
Number
Contents Contents of Indication on minute Contents of Indication on second Remarks
0 Indication for the
inner data of
IC6001
VHS mode
(Real time)
Process number of the mechanism
movement
(Real time)
1 Indication for the
inner data of
IC6001
Tape beginning and ending detection
data (Real time)
Key code
(Real time)
00: Both tape beginning and ending
have not been detected
01: Tape ending is detecting now
02: Tape beginning is detecting now
03: Both tape beginning and ending
are detecting now
Indicate the receiving code when the
key of VCR or remote controller
being operated.
2 Indication for the
inner data of
IC6001
Mechanism position (Real time) Ordering for the Motors (Real time) The following functions are prohib-
ited to operate the mechanism with-
out cassette tape.
lTape beginning and ending detec-
tion.
lReel lock detection
lTape detection and tape position
detection
Press the EJET key for over 3 sec-
onds in this mode, and then the VCR
is shifted into the special modes,
such as PG Adjustment, Model Code
Setting, and so on.
The orders for the motors are as fol-
lows.
0L: EJECT position
02: DOWN position
03: RREW position
04: LOAD position
05: REV position
06: PLAY position
07: POFF position
08: STOP_R position
09: STOP_F position
0 - : FF/REW position
0_ : Intermediate between each
positions
0*, 2*: CYL off,
CAP off
1*: CYL off,
CAP on (fwd)
3*: CYL off,
CAP on (rev)
8*, A*: CYL on,
CAP off
9*: CYL on,
CAP on (fwd)
B*: CYL on,
CAP on (rev)
*0: Motor off
*1: Loading
*2: Unloading
*3: Break (Load + Unload)
3 Self-diagnosis his-
tory (1st)
1st history of error number "- -" is displayed.
4 Self-diagnosis his-
tory (2nd)
2nd history of error number "- -" is displayed
5 Self-diagnosis his-
tory (3rd)
3rd history of error number "- -" is displayed
6 Indication for the
inner data of
IC6001
Servo data (4 digits)
(Real time)
7 Manual mecha-
nism operation
Mechanism position (Real time) Ordering for the Motors Press the following key;
PLAY key : Loading
STOP key : Unloading
0L: EJECT position
02: DOWN position
03: RREW position
04: LOAD position
05: REV position
06: PLAY position
07: POFF position
08: STOP_R position
09: STOP_F position
0 - : FF/REW position
0 _: Intermediate between each
positions
0*, 2*: CYL off,
CAP off
1*: CYL off,
CAP on (fwd)
3*: CYL off,
CAP on (rev)
8*, A*: CYL on,
CAP off
9*: CYL on,
CAP on (fwd)
B*: CYL on,
CAP on (rev)
*0: Motor off
*1: Loading
*2: Unloading
*3: Break (Load + Unload)
