Panasonic DMR-EZ49VEB

S-6
S2.4. FL_Drive P.C.B.
REF No. PIN No. REC PB EE
IC7501 1 0 0 0
IC7501 2 0 0 0
IC7501 3 0 0 0
IC7501 4 0 0 0
IC7501 5 2.8 2.8 2.8
IC7501 6 0.3 0.3 0.3
IC7501 7 0.3 0.3 0.3
IC7501 8 4.6 4.6 4.6
IC7501 9 4.2 4.2 4.2
IC7501 10 0.1 0.1 0.1
IC7501 11 0.1 0.1 0.1
IC7501 12 0 0 0
IC7501 13 4.7 4.7 4.7
IC7501 14 -17.8 -17.8 -20.7
IC7501 15 -17.8 -17.8 -20.7
IC7501 16 -9.3 -9.3 -20.7
IC7501 17 -17.8 -17.8 -17.9
IC7501 18 -20.7 -20.7 -20.7
IC7501 19 -17.9 -17.9 -20.7
IC7501 20 -6.5 -6.5 -20.7
IC7501 21 -15 -15 -17.9
IC7501 22 -0.1 -0.1 -15.1
IC7501 23 -9.4 -9.4 -12.2
IC7501 24 -9.4 -9.4 -20.7
IC7501 25 -17.9 -17.9 -20.7
IC7501 26 -20.7 -20.7 -20.7
IC7501 27 -20.7 -20.7 -20.7
IC7501 28 -20.7 -20.7 -20.7
IC7501 29 -12.2 -12.2 -20.8
IC7501 30 -21.4 -21.4 -21.4
IC7501 31 - - -
IC7501 32 - - -
IC7501 33 - - -
IC7501 34 - - -
IC7501 35 - - -
IC7501 36 -18.4 -18.4 -18.4
IC7501 37 -18.1 -18.1 -18.1
IC7501 38 -18.1 -18.1 -18.1
IC7501 39 -18.1 -18.1 -18.1
IC7501 40 -18.1 -18.1 -18.1
IC7501 41 -18.1 -18.1 -18.1
IC7501 42 -18.1 -18.1 -18.1
IC7501 43 4.7 4.7 4.7
IC7501 44 0 0 0
Q7502 E -18.5 -18.5 -18.5
Q7502 C 4.7 4.7 4.7
Q7502 B -18.4 -18.4 -18.4
QR7502 E 0 0 0
QR7502 C 0 0 0
QR7502 B 4.6 4.6 4.6
QR7503 E 0 0 0
QR7503 C 5.1 5.1 5.1
QR7503 B 0 0 0
QR7504 E 0 0 0
QR7504 C 5.1 5.1 5.1
QR7504 B 0 0 0
