Panasonic DMR-EZ49VEB

S-4
S2.2. SD_USB P.C.B.
REF No. PIN No. REC PB EE
IC38002 1 0 0 3.3
IC38002 2 0 0 0
IC38002 3 3.3 3.3 3.3
IC38002 4 5 5 5
IC38002 5 5 5 0.3
S2.3. Digital_IF P.C.B.
REF No. PIN No. REC PB EE
IC9301 1 1.2 1.2 1.2
IC9301 2 0 0 0
IC9301 3 4.7 4.7 4.7
IC9301 4 6.1 6.1 6.1
IC9301 5 5 5 5
IC9700 1 1.7 1.7 1.7
IC9700 2 5 5 5
IC9700 3 0 0 0
IC9701 1 2.4 2.4 2.4
IC9701 2 4.3 4.3 4.3
IC9701 3 5 5 5
IC9701 4 4.7 4.7 4.7
IC9701 5 0.1 0.1 0.1
IC9701 6 - - -
IC9701 7 4.3 4.3 4.3
IC9701 8 0 0 0
IC9701 9 0 0 0
IC9701 10 0.8 0.8 0.8
IC9701 11 1.2 1.2 1.2
IC9701 12 4.6 4.6 4.6
IC9701 13 2 2 2
IC9701 14 0 0 0
IC9701 15 1.8 1.8 1.8
IC9701 16 3.3 3.3 3.3
IC9701 17 4.7 4.7 4.7
IC9701 18 3.3 3.3 3.3
IC9701 19 3.2 3.2 3.2
IC9701 20 0 0 0
IC9701 21 3 3 3
IC9701 22 1.3 1.3 0
IC9701 23 3.2 3.2 3.2
IC9701 24 - - -
IC9701 25 3.2 3.2 3.2
IC9701 26 3.2 3.2 3.2
IC9701 27 1.7 1.7 1.7
IC9701 28 3 3 3
IC9701 29 3.3 3.3 3.3
IC9701 30 3.3 3.3 3.3
IC9701 31 3.3 3.3 3.3
IC9701 32 3.3 3.3 3.3
IC9701 33 0 0 0
IC9701 34 - - -
IC9701 35 0.7 0.7 0.7
IC9701 36 3.2 3.2 3.2
IC9701 37 3.2 3.2 3.2
IC9701 38 3.3 3.3 3.3
IC9701 39 2.5 2.5 2.5
IC9701 40 4.8 4.8 4.8
IC9701 41 0 0 0
IC9701 42 4.6 4.6 4.6
IC9701 43 4.6 4.6 4.6
IC9701 44 4.7 4.7 4.7
IC9701 45 2.9 2.9 2.9
IC9701 46 4.7 4.7 4.7
IC9701 47 4.6 4.6 4.6
IC9701 48 0 0 0
IC9701 49 - - -
IC9701 50 0 0 0
IC9701 51 - - -
IC9701 52 - - -
IC9701 53 0 0 0
IC9701 54 0 0 0
IC9701 55 0 0 0
IC9701 56 0 0 0
IC9701 57 - - -
IC9701 58 - - -
REF No. PIN No. REC PB EE
IC9701 59 - - -
IC9701 60 5 5 5
IC9701 61 - - -
IC9701 62 4.7 4.7 4.7
IC9701 63 4.6 4.6 4.6
IC9701 64 0 0 0
IC9701 65 - - -
IC9701 66 0 0 0
IC9701 67 0 0 0
IC9701 68 0 0 0
IC9701 69 - - -
IC9701 70 - - -
IC9701 71 4.6 4.6 4.6
IC9701 72 - - -
IC9701 73 3.3 3.3 3.3
IC9701 74 4.9 4.9 4.9
IC9701 75 4.7 4.7 4.7
IC9701 76 0 0 0.1
IC9701 77 - - -
IC9701 78 0 0 0
IC9701 79 0 0 0
IC9701 80 3.9 3.9 3.9
IC9701 81 0 0 0
IC9701 82 3.3 3.3 3.3
IC9701 83 0 0 0
IC9701 84 2 2 2
IC9701 85 0 0 0
IC9701 86 4.7 4.7 4.7
IC9701 87 4.7 4.7 4.7
IC9701 88 4.7 4.7 4.7
IC9701 89 2 2 2
IC9701 90 4.7 4.7 4.7
IC9701 91 0 0 0
IC9701 92 0 0 0
IC9701 93 2.6 2.6 2.6
IC9701 94 1.6 1.6 1.6
IC9701 95 1.2 1.2 1.2
IC9701 96 0 0 0
IC9701 97 0 0 0
IC9701 98 1.8 1.2 1.9
IC9701 99 4.7 4.7 4.7
IC9701 100 4 4 4
IC9702 1 3.3 3.3 3.3
IC9702 2 3.3 3.3 3.3
IC9702 3 0 0 0
IC9702 4 - - -
IC9702 5 - - -
IC9703 1 4.9 4.9 4.9
IC9703 2 6.1 6.1 6.1
IC9703 3 0 0 0
IC9703 4 - - -
IC9703 5 - - -
IC9705 1 0 0 0
IC9705 2 0 0 0
IC9705 3 0 0 0
IC9705 4 0 0 0
IC9705 5 3.2 3.2 3.2
IC9705 6 3.2 3.2 3.2
IC9705 7 0 0 0
IC9705 8 3.3 3.3 3.3
IC9706 1 4.6 4.6 4.6
IC9706 2 4.7 4.7 4.7
IC9706 3 0 0 0
IC9706 4 0 0 0
IC9706 5 0 0 0
IC9708 1 6.1 6.1 6.1
REF No. PIN No. REC PB EE
IC9708 2 0 0 0
IC9708 3 6 6 6
IC9708 4 - - -
IC9708 5 5 5 5
IC11150 1 2.2 2.2 2.2
IC11150 2 1.7 1.7 1.7
IC11150 3 0 0 0
IC11150 4 15 15 15
IC11150 5 0 0 0
IC11150 6 - - -
IC11150 7 - - -
IC11150 8 - - -
IC11150 9 - - -
IC11201 1 0 0 0
IC11201 2 0 0 0
IC11201 3 7.9 7.9 7.9
IC11201 4 2.5 2.5 2.5
IC11370 1 3.8 3.8 3.8
IC11370 2 6.1 6.1 6.1
IC11370 3 0 0 0
IC11370 4 5.1 5.1 5.1
IC11370 5 1.2 1.2 1.2
IC11700 1 12.4 12.4 12.4
IC11700 2 4.4 4.4 4.4
IC11700 3 1.1 1.1 1.1
IC11700 4 1 1 1
IC11700 5 1.1 1.1 1.1
IC11700 6 0 0 0
IC11700 7 8.8 8.8 8.8
IC11700 8 12.4 12.4 12.4
IC11750 1 3.8 3.8 3.8
IC11750 2 3.8 3.8 3.8
IC11750 3 3.3 3.3 3.3
IC11750 4 1.2 1.2 1.2
IC11750 5 0 0 0
IC14301 1 4.4 4.4 4.4
IC14301 2 4.6 4.6 4.6
IC14301 3 0 0 0
IC14301 4 1.2 1.2 1.2
IC14301 5 1.2 1.2 1.2
IC14301 6 0.6 0.6 0.6
IC14301 7 5.5 5.5 5.5
IC14301 8 5.4 5.4 5.4
IC14301 9 1.2 1.2 1.2
IC14301 10 0 0 0
IC14301 11 6 6 6
IC14301 12 4.4 4.4 4.4
IC14301 13 6.1 6.1 6.1
IC14301 14 7.4 7.4 7.4
IC14301 15 10.1 10.1 10.1
IC14301 16 12.4 12.4 12.4
