DMR-EZ49VEBK vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
C7841 F1H1H101A004 50V 100P 1 EZ49VEGK.EZ49VEGS LB7304 J0JBC0000134 COIL 1 EZ49VEGK.EZ49VEGS
C7842 F1H1H103A219 50V 0.01U 1 EZ49VEGK.EZ49VEGS LB7305 J0JBC0000134 COIL 1 EZ49VEGK.EZ49VEGS
LB7306 J0JBC0000134 COIL 1 EZ49VEGK.EZ49VEGS
D2001 B0AACK000004 DIODE 1 E.S.D. LB7401 J0JHC0000032 COIL 1
D2002 B0AACK000004 DIODE 1 E.S.D. LB7402 J0JHC0000032 COIL 1
D2502 B0BA01600007 DIODE 1 E.S.D. LB7403 J0JHC0000032 COIL 1
D3901 B0AACK000004 DIODE 1 E.S.D. LB7801 J0JGC0000063 COIL 1
D4501 B0AACK000004 DIODE 1 E.S.D. LB7802 J0JGC0000063 COIL 1 EZ49VEGK.EZ49VEGS
D4502 B0BA5R700008 DIODE 1 E.S.D. LB7803 J0JGC0000063 COIL 1
D4901 B0JCDD000001 DIODE 1 E.S.D. LB7804 J0JBC0000134 COIL 1 EZ49VEGK.EZ49VEGS
D6306 B0BA5R700008 DIODE 1 E.S.D. LB7805 J0JBC0000134 COIL 1
D6501 B3EA00000072 LED 1 E.S.D.
D7801 B0BA03000015 DIODE 1 E.S.D. P2501 K1MN07A00030 CONNECTOR(7P) 1
D7802 B0JAMD000026 DIODE 1 EZ49VEGK.EZ49VEGS E.S.D. P2571 K1KA08A00355 CONNECTOR(8P) 1
P3001 K1MN09A00029 CONNECTOR(9P) 1
IC2501 C1AB00001767 IC 1 E.S.D. P4001 K1KB02A00035 CONNECTOR(2P) 1
IC3001 C1AB00002084 IC 1 E.S.D. P4002 K1MN06A00042 CONNECTOR(6P) 1
IC3002 C0CBCDD00026 IC 1 E.S.D. P6001 K1KB19AA0032 CONNECTOR(19P) 1
IC3901 C1AB00003267 IC 1 E.S.D. P6002 K1KB19AA0032 CONNECTOR(19P) 1
IC3905 C1AB00001340 IC 1 E.S.D. P6003 K1KB23A00004 CONNECTOR(23P) 1
IC4501 AN3656NFBPBV IC 1 E.S.D. P6004 K1KB13AA0032 CONNECTOR(13P) 1
IC6001 C2CBHF000476 IC 1 E.S.D. P6531 K1KA02A00375 CONNECTOR(2P) 1
IC6302 C0CBCDC00020 IC 1 E.S.D. P7401 K1KA11AA0031 CONNECTOR(11P) 1
IC6501 B3NAA0000118 IC 1 E.S.D. P7402 K1KA11AA0031 CONNECTOR(11P) 1
IC6502 B3NAA0000118 IC 1 E.S.D.
IC7301 C1AB00002845 IC 1 EZ49VEGK.EZ49VEGS E.S.D. PS6002 K1KB12B00047 CONNECTOR(12P) 1
IC7302 C0EBE0000366 IC 1 EZ49VEGK.EZ49VEGS E.S.D.
IC7304 C0CBCAC00242 IC 1 EZ49VEGK.EZ49VEGS E.S.D Q3002 B1ABDF000026 TRANSISTOR 1 E.S.D.
IC7401 C0CBCDC00052 IC 1 E.S.D. Q3901 B1ADCF000172 TRANSISTOR 1 E.S.D.
IC7402 C0CBCDC00052 IC 1 E.S.D. Q4001 B1ABCL000022 TRANSISTOR 1 E.S.D.
IC7403 C0DBGHD00011 IC 1 E.S.D Q4002 B1ABDF000026 TRANSISTOR 1 E.S.D.
IC7801 C0DBGYY00033 IC 1 EZ49VEGK.EZ49VEGS E.S.D Q4003 B1ABHC000001 TRANSISTOR 1 E.S.D.
Q4004 B1ADLB000006 TRANSISTOR 1 E.S.D.
JK3901 K1FB121B0018 JACK, (AV1) 1 Q4501 B1AAGD000016 TRANSISTOR 1 E.S.D.
JK3902 K1FB121B0018 JACK, (AV2) 1 Q4502 B1ADLB000006 TRANSISTOR 1 E.S.D.
JK4901 K2HA306B0081 JACK, (VIDEO/AUDIO OUT) 1 Q4901 B1ADLB000006 TRANSISTOR 1 E.S.D.
Q6102 B1ABDF000026 TRANSISTOR 1 E.S.D.
K2597 ERJ3GEY0R00V 1/10W 0 1 Q6103 B1ABDF000026 TRANSISTOR 1 E.S.D.
K4001 ERJ3GEY0R00V 1/10W 0 1 Q6104 B1ADCF000172 TRANSISTOR 1 E.S.D.
K7401 J0JDC0000092 COIL 1 Q6305 B1ABDF000033 TRANSISTOR 1 E.S.D.
K7402 ERJ3GEY0R00V 1/10W 0 1 Q6501 PNB2303M01VT TRANSISTOR 1 E.S.D.
K7809 ERJ3GEY0R00V 1/10W 0 1 EZ49VEGK.EZ49VEGS Q6502 PNB2303M01VT TRANSISTOR 1 E.S.D.
Q7802 B1ABDF000026 TRANSISTOR 1 EZ49VEGK.EZ49VEGS E.S.D.
L3001 G0C820JA0019 COIL 1 Q7803 B1ABDF000026 TRANSISTOR 1 EZ49VEGK.EZ49VEGS E.S.D.
L3002 G0C270JA0019 COIL 27UH 1
L3003 G0C390JA0019 COIL 1 QR4004 B1GDCFJJ0037 TRANSISTOR 1 E.S.D.
L3004 G0C680JA0019 COIL 68UH 1 QR4005 B1GBCFNN0041 TRANSISTOR 1 E.S.D.
L3006 G0C270JA0019 COIL 27UH 1 QR4501 B1GBCFJJ0040 TRANSISTOR 1 E.S.D.
L3007 ELJFA120KFB COIL 1 QR4901 B1GBCFJJ0040 TRANSISTOR 1 E.S.D.
L4001 G0C221KA0073 COIL 220UH 1 QR4911 B1GDCFNN0024 TRANSISTOR 1 E.S.D.
L4502 G0C1R2J00004 COIL 1.2UH 1 QR4912 B1GBCFGA0027 TRANSISTOR 1 E.S.D.
L4503 G0C101JA0019 COIL 100UH 1 QR4913 B1GBCFGA0027 TRANSISTOR 1 E.S.D.
L5001 G0C680JA0019 COIL 68UH 1
L6103 G0C1R5JA0019 COIL 1.5UH 1 R2001 ERJ3GEYJ392V 1/10W 3.9K 1
L6105 G0C680JA0019 COIL 68UH 1 R2002 ERJ3GEYJ105V 1/10W 1M 1
L7301 G0C2R2JA0019 COIL 2.2UH 1 EZ49VEGK.EZ49VEGS R2099 ERJ3GEYJ682V 1/10W 6.8K 1
L7801 G0C100JA0019 COIL 10UH 1 EZ49VEGK.EZ49VEGS R2501 ERJ6GEYJ1R2V 1/8W 1.2 1
L7802 G1CR56JA0020 COIL 56UH 1 R2502 ERJ6GEYJ1R5V 1/8W 1.5 1
L7803 G1CR56JA0020 COIL 56UH 1 R2503 ERDS2TJ103T 1/4W 10K 1
R2514 ERJ3GEYJ221V 1/10W 220 1
LB3901 J0JGC0000020 COIL 1 R2515 ERJ3GEYJ221V 1/10W 220 1
LB4002 J0JBC0000070 COIL 1 R2516 ERJ3GEYJ221V 1/10W 220 1
LB4003 J0JBC0000070 COIL 1 R2520 ERJ3GEYJ183V 1/10W 18K 1
LB4101 J0JBC0000041 COIL 1 R2521 ERJ3GEYJ102V 1/10W 1K 1
LB4102 J0JHC0000021 COIL 1 R2551 ERJ3GEYJ103V 1/10W 10K 1
LB4103 J0JBC0000011 COIL 1 R2552 ERJ3GEYJ103V 1/10W 10K 1
LB4104 J0JBC0000011 COIL 1 R2561 ERJ3GEYJ102V 1/10W 1K 1
LB4105 J0JBC0000011 COIL 1 R2562 ERJ3GEYJ473V 1/10W 47K 1
LB4106 J0JBC0000011 COIL 1 R2563 ERJ3GEYJ102V 1/10W 1K 1
LB4901 J0JGC0000020 COIL 1 R2564 ERJ3GEYJ101V 1/10W 100 1
LB4906 ERJ3GEY0R00V 1/10W 0 1 R2565 ERJ3GEYJ101V 1/10W 100 1
LB4963 J0JCC0000103 COIL 1 R3001 ERJ3GEYJ152V 1/10W 1.5K 1
LB4965 J0JCC0000103 COIL 1 R3002 ERJ3GEYJ622V 1/10W 6.2K 1
LB6002 J0JHC0000032 COIL 1 R3003 ERJ3GEYJ562V 1/10W 5.6K 1
LB7301 ERJ6GEY0R00V 1/8W 0 1 EZ49VEGK.EZ49VEGS R3005 ERJ3GEYJ122V 1/10W 1.2K 1
LB7302 J0JBC0000134 COIL 1 EZ49VEGK.EZ49VEGS R3008 ERJ3GEYJ106V 1/10W 10M 1
LB7303 J0JBC0000134 COIL 1 EZ49VEGK.EZ49VEGS R3010 ERJ3GEYJ153V 1/10W 15K 1
S-91
