5.6. Cover Assembly
Safety
Mark
Ref.
No.
Parts Number Part Name Supplier Remarks Destination
601
PJKEB0081Z
Cover, Front
For UF-9000 AU
PJKEB0081Y For DP-190 AU
PJKEB0081X For DP-180 Except AU
602 PJHRB0567Z Support, Right Paper All
603 PJHRB0568Z Support, Left Paper All
604 PJHRB0045Z Rack, Guide OAPD All
605 PJHRB0046Z Gear, Paper Guide Pinion OAPD All
606 PJBAB0011Z Hook OAPD All
607 PJYK4P7305M
Assembly, Pinch Roller
Holder
OAPD All
608 PJDSB0034Z Spring, Pinch Roller OAPD All
609 PJDSB0145Z Spring, Cleaning Roller OAPD All
610 PJDRB0017Z Roller, Pinch OAPD All
611 PJDRB0093Z Roller, Cleaning OAPD All
612 PJYKF2300AU Door, Rear All
613 PJDFB0008Z Shaft, Roller OAPD All
614 PJDSB0112Z Spring OAPD All
615 PJKEB0110Z Cover, Right Side All
616 PJKEB0111Z Cover, Left Side All
617 PJKEB0112Z Cover, Rear All
618 PJKEB0116Z Cover , Right Leg All
619 PJKEB0117Z Cover, Left Leg All
620 PJKEB0118Z Cover, PCB All
621 DZMA003267 Cover, Flash Memory Card All
622 PJQTB0264Z Sheet, Right Cover All
623 PJKEB0113Z Cover, Top All
624 PJKEB0114Z Tray, Sub Paper All
625 PJKEB0130Z Cover, Rear Paper Tray All
626
DZDU000025
Handset
Refer to 5.1.1.
Except AK
DZDU000027 AK
627
DZJE000738
Cradle, Upper
AU
DZMA000260 Except AU
628
DZJE000740
Cradle, Lower
AU
DZMA000269 Except AU
629 DZFN000060 Cord, Handset All
630
DZFN000082
Cord, Cradle
Except AK
DZFN000115 AK
