Panasonic DP-190 - Left Side Parts

134
JUN 2004
Ver. 2.0
UF-9000
DP-180/190
5.9. Left Side Parts
Safety
Mark
Ref.
No.
Parts Number Part Name Supplier Remarks Destination
1001 PJDSB0033Z Spring, Grid OAPD All
1002 PJDSB0148Z Spring, Charge OAPD All
1003 PJDSB0009Y Spring, OPC OAPD All
1004 PJDSB0149Z Spring, Developer OAPD All
1005 N0GG4E000002 HVPS OAPD All
1006 L6FALEGK0009 Motor, Fan OAPD All
1007 PJNEB0008Z Screw OAPD All
1009 PJDRB0059Z Roller, Sub OAPD All
1010 PJDSB0019Z Spring OAPD All
1011 PJMDB0291Z Bracket, Side Cover A All
1012 PJMDB0289Z Bracket, Side Cover B All
1013 PJMDB0290Z Bracket, Left Side Cover All
1014 PJMDB0258Z Stay, Rear All
1015 PJMDB0260Z Base, Left Side All
1016 PJMDB0262Z Bracket, Left Side All
1017 PJMDB0263Z Bracket Left Rear All
1018 PJMDB0264Z Bracket, Right Rear All
1019 PJHRB0659Y Guide, Exit Paper All
1020 PJQTB0263Z Sheet, HVPS Insulation All
1021
PJWPWU00001Z
Assembly, LVPS
For UF-9000/
DP-190
AU
PJWPF2300EB For DP-180
Except AU
1022 PJHE5065Z Screw OAPD All
610 PJDRB0017Z Roller, Pinch OAPD All
613 PJDFB0008Z Shaft, Roller OAPD All
2403 DZJK000057 Edge Saddle All
2404 DZJK000067 Clamp All
2405 DZJK000004 Clamp All
P3 XTW3+8L Screw All
T9 XTW3+8S Screw OAPD All
U1 XTW3+6L Screw All
U3 XYC3+FF8C Screw OAPD All
