18.3. Traverse Section Exploded View
When replacing parts, lubricate the parts marked “×××” in the diagram.
Parts number Service Tool
Screw lock RZZ0L01 Three-bond 1401C
Lubricating oil JZS0648 Froil 946P
Grease JGS0101 MC grease PD No.10
61
DVD-RV60
